Appendix D. Cables/Adapters for SSR activities
This section shows the cables required for installing and conguring code on the server.
Figure 92. USB-A to Ethernet adapter
Figure 93. Mini USB to VGA/HDMA adapter
Note: The gure shows mini USB (ESS 3200), micro USB is need for ESS 3500.
Figure 94. Serial (USB mini-B) to USB cable
Note: The cable shown in the gure works for ESS 3200/ESS 3500 enclosures.
©
Copyright IBM Corp. 2021, 2022 119
