IBM Elastic Storage System 3200

Table 19. Summary of onboard ports (continued)
Onboard Port Speed Function
TP (Technician Port) - USB type
mini-B
N/A Fixed IP address from factory for
service and hardware conguration
Left canister:
Right canister:
User ID: essserv1
Password:
• Left canister - {Serial # of
enclosure} A
• Right canister - {Serial # of
enclosure} B
Example: Enclosure serial 78E00TF
• Left canister password:
78E00TFA
• Right canister password:
78E00TFB
Serial number of the enclosure
can be obtained from the front
tag located at the left side of the
enclosure.
Each IBM Elastic Storage System 3200 system requires two Ethernet cables to connect it to an Ethernet
switch. One cable connects to the Ethernet port of the left server canister, and the other cable connects to
Ethernet port of the right server canister.
Each IBM Elastic Storage System 3200 server canister has two PCIe interface slots to support optional
host interface adapters. The host interface adapters can be supported in any of the interface slots. The
following table provides an overview of the host interface adapters.
Table 20. Summary of supported host interface adapters
Protocol Feature Ports FRU part
number
Quantity supported
200 Gb IB-HDR/
Ethernet
AJZL 2 per adapter 01LL648 2-4
100 Gb Ethernet AJZN 2 per adapter 01LL634 2-4
Note: Each server canister within the IBM Elastic Storage System 3200 system (building block) must be
congured with the same host interface adapters.
Planning for adapters
IBM Elastic Storage System 3200 contains two server canisters. Each server canister has two PCIe
interface slots to support extra adapters. InniBand and Ethernet adapters are supported in any of the
interface slots. In addition, each server canister contains one Onboard Ethernet port and one SSR access
port.
Important: Both server canisters in an IBM Elastic Storage System 3200 system (same building block)
must be congured with the same adapters. Both server canisters must have identical conguration.
