no spanning-tree loopback-detection
no shutdown
exit
interface ethernet 1/13-20
switchport mode access
switchport allowed vlan add 101 untagged
switchport native vlan 101
switchport allowed vlan remove 1
no shutdown
exit
interface ethernet 1/21-22
switchport mode hybrid
switchport native vlan 100
switchport allowed vlan add 100 untagged
switchport allowed vlan add 101 tagged
spanning-tree spanning-disabled
switchport allowed vlan remove 1
no shutdown
exit
interface ethernet 1/23
shutdown
no loopback-detection
spanning-tree spanning-disabled
exit
interface ethernet 1/24
switchport allowed vlan add 1305 untagged
switchport mode access
switchport native vlan 1305
switchport allowed vlan remove 1
no shutdown
exit
interface vlan 1305
ip address dhcp
exit
exit
copy running-config startup-config
Up to this point the conguration is always the same for every switch, the following lines are different for
each switch. You need to know the serial number of the switch to continue. To get the serial, run show
version command as shown in the following example:
Vty-1#show version
Unit 1
Serial Number : EC2028001435
Hardware Version : R02A
Number of Ports : 28
Main Power Status : Up
Role : Master
Loader Version : 1.0.1.9
Linux Kernel Version : 2.6.19-g496f2361-di
Operation Code Version : 1.2.71.203
In this example, the serial number EC2028001435 is used. You need to use the serial number of each
switch on the commands.
configure
username guest password 0 EC2028001435
username admin password 0 EC2028001435
exit
copy running-config startup-config
exit
At this point, you are disconnected from the switch and the switch is personalized for ESS usage.
Appendix C. Dual 24 port (48 ports) MGMT switch ESS
conguration117
