18 Technical specifications
Technical specifications
Physical
characteristics
The following table lists the physical characteristics of the CN1610 switch:
Network protocol
and standards
compatibility
The CN1610 switch supports the following network protocols and standards:
u IEEE 802.3i 10Base-T
u IEEE 802.3u 100Base-TX
u IEEE 802.3x Flow-Control
u IEEE 802.3ab 1000Base-T
u IEEE 802.3z 1000Base-X
u IEEE 802.3ae 10 Gpbs Ethernet over fiber
Environmental
specification
The following table lists the environmental specification for the CN1610 switch:
Specification Measurement
Height 43 mm (1.69 in)
Width 445 mm (17.5 in)
Depth 508 mm (20 in)
Weight 10.2 kg (22.5 lbs)
Specification Measurement
Operating temperature: 10 to 40°C
Storage temperature -40 to 70°C
Operating relative humidity 20 to 80% noncondensing
Storage relative humidity 10 to 95% noncondensing
