If the rightmost hexadecimal digit of offset 000182 is 2, then the unit address is hexadecimal offset 192
- 195
Record this address information. Return to the procedure that sent you here, if one.
6. Using hexadecimal arithmetic, add the value in offsets 170 - 173, the value in offsets 174 - 177, and
00000002. For example, 000001C8 + 00000410 + 00000002 = 000005DA.
If the value of the rightmost hexadecimal digit at this offset is 8: Using hexadecimal arithmetic, add
0000000A to the offset you calculated. This will be the location of the unit address in the form
abcdefgh. For example, 00005DA + 0000000A = 000005E4.
If the value of the rightmost hexadecimal digit at this offset is 2: Using hexadecimal arithmetic, add
00000010 to the offset you calculated. This will be the location of the unit address in the form
abcdefgh. For example, 00005DA + 00000010 = 000005EA.
Record this address information. If you were sent here from another procedure, return to the
procedure that sent you here.
This ends the procedure.
Display Hexadecimal Report for Resource
Serial Resource
Name Type Model Number Name
STORAGE 6512 001 10-4294009 SI05
Offset 0123 4567 89AB CDEF EBCDIC
000180 D0007800 65120001 34000620 1100FFFF }...............
000190 FFFFFFFF 31090000 00001100 03C00000 .............{..
0001A0 00000000 00000000 00000000 00000000 ................
0001B0 00000000 00000000 00000000 00000000 ................
0001C0 00000000 00000000 00000000 E0000008 ................
0001D0 00000000 00000000 00000000 00000000 ................
0001E0 00000018 00000002 E00401F0 10002000 ...........0....
0001F0 00000000 40000000 00000000 000002CC .... ...........
000200 CCCC0000 00000000 00800000 00000000 ................
000210 08100000 00000000 F0200040 00800000 ........0.. ....
000220 00000000 04000000 08000040 E000E221 ........... ..S.
000230 800084F3 00000002 0000001B 110003C0 ...3...........{
More...
Press Enter to continue.
F3=Exit F12=Cancel
Figure 10. Example of hexadecimal report for resource offset location (where the rightmost hexadecimal digit of offset
000182 is 8)
Display Hexadecimal Report for Resource
Serial Resource
Name Type Model Number Name
STORAGE 571A 001 10-4294009 DC01
Offset 0123 4567 89AB CDEF EBCDIC
000180 F8407200 F5F7F1C1 F0F0F0F1 3400031D 8 ..571A0001....
000190 00233104 00FFFFF4 F0F0F0F0 F0F0F0F0 .......400000000
0001A0 1104E255 F0F0F0F0 F0F0F0F0 40404040 ..S.00000000
0001B0 40404000 00FF0000 04440000 A1D0038D ..........}..
0001C0 0713000C 00000000 00000000 70000200 ................
More...
Press Enter to continue.
F3=Exit F12=Cancel
Figure 11. Example of hexadecimal report for resource offset location (where the rightmost hexadecimal digit of offset
000182 is 2)
Common service procedures 31

IBM Power System POWER7 Series Specifications

General

Processor	POWER7
L2 Cache	256 KB per core
L3 Cache	4 MB per core
Memory Type	DDR3
Operating System	AIX, IBM i, Linux
Virtualization	PowerVM
Processor Cores	4, 6, or 8
Form Factor	Rack
Release Date	2010
