3. Press F6 to display the hexadecimal report.
The direct select address (DSA) is in the format BBBB-Cc-bb:
v BBBB means hexadecimal offsets 4C and 4D.
v Cc means hexadecimal offset 51.
v bb means hexadecimal offset 4F.
4. Are offsets 170 - 173 equal to 00000000?
v Yes: Continue with step 5.
v No: Continue with step 6 on page 31.
5. Page forward until you locate the offset location X'000180'.
If the rightmost hexadecimal digit of offset 000182 is 8, then the unit address is hexadecimal offset
18C - 18F.
Display Detail Report for Resource
Serial Resource
Name Type Model Number Name
STORAGE 6512 001 10-4294009 SI05
LogID .........: 06020132 Sequence.......: 2248
Date ..........: 05/20/95 Time.........: 08:37:55
Reference code .....: 3400 Secondary code....: 00000000
Table ID ........: 65120001 IPL source/state...: B/7
Class..........: Permanent
System Ref Code.....: 65123400
I/O processor card detected device error
Press Enter to continue.
F3=Exit F6=Hexadecimal report
F9=Address Information F10=Previous detail report F12=Cancel
Figure 8. Example of hexadecimal detail report for resource
Display Hexadecimal Report for Resource
Serial Resource
Name Type Model Number Name
STORAGE 6512 001 10-4294009 SI05
Offset 0123 4567 89AB CDEF EBCDIC
000000 C5D3F0F4 00000160 00E00180 77B7695E EL04...-.......;
000010 E8A70000 000008C8 20E00602 01320000 Y......H........
000020 34000000 11000000 00000000 009C0000 ................
000030 F6F5F1F2 F0F0F140 F1F060F4 F2F9F4F0 6512001 10-42940
000040 F0F9F6F5 F1F20000 00000001 00060000 096512..........
000050 00020000 FFFFFFFF FFFFFFFF FFFF0000 ................
000060 00000000 00000000 00000000 F4404040 ............4
000070 40000000 00000000 00000000 00000000 ...............
000080 00000000 00000000 00000000 00000000 ................
000090 00000000 00000000 00000000 00000000 ................
0000A0 00000000 00000000 00000000 00000000 ................
0000B0 00000000 00000000 40404040 40404040 ........
More...
Press Enter to continue.
F3=Exit F12=Cancel
Figure 9. Example of hexadecimal report for resource
30

IBM Power System POWER7 Series Specifications

General

Processor	POWER7
L2 Cache	256 KB per core
L3 Cache	4 MB per core
Memory Type	DDR3
Operating System	AIX, IBM i, Linux
Virtualization	PowerVM
Processor Cores	4, 6, or 8
Form Factor	Rack
Release Date	2010
