Table 9. Format 01 (continued)
Description Hex offset
New device 1 serial number 0001F6 - 0001F9
Device 1 IOA type and model 0001FA - 0001FD
Device 1 IOA serial number 0001FE - 000201
Device 1 Cache type and model 000202 - 000205
Device 1 Cache serial number 000206 - 000209
Device 2 type 00021E - 000221
Device 2 serial number 000222 - 000225
Device 2 unit address 000226 - 000229
New device 2 type 00022A - 00022D
New device 2 serial number 00022E - 000231
Device 2 IOA type and model 000232 - 000235
Device 2 IOA serial number 000236 - 000239
Device 2 cache type and model 00023A - 00023D
Device 2 cache serial number 00023E - 000241
Device 3 type 000256 - 000259
Device 3 serial number 00025A - 00025D
Device 3 unit address 00025E - 000261
New device 3 type 000262 - 000265
New device 3 serial number 000266 - 000269
Device 3 IOA type and model 00026A - 00026D
Device 2 IOA serial number 00026E - 000271
Device 3 cache type and model 000272 - 000275
Device 3 cache serial number 000276 - 000279
Table 10. Format 02
Description Hex offset
Array member 0 type 0001D6 - 0001D9
Array member 0 serial number 0001DA - 0001DD
Array member 0 expected unit address 0001DE - 0001E1
Array member 0 current unit address 0001E2 - 0001E5
Array member 1 type 0001E6 - 0001E9
Array member 1 serial number 0001EA - 0001ED
Array member 1 expected unit address 0001EE - 0001F1
Array member 1 current unit address 0001F2 - 0001F5
Array member 2 type 0001F6 - 0001F9
Array member 2 serial number 0001FA - 0001FD
Array member 2 expected unit address 0001FE - 000201
Array member 2 current unit address 000202 - 000205
Array member 3 type 000206 - 000209
Array member 3 serial number 00020A - 00020D
40
