Table 10. Format 02 (continued)
Description Hex offset
Array member 3 expected unit address 00020E - 000211
Array member 3 current unit address 000212 - 000215
Array member 4 type 000216 - 000219
Array member 4 serial number 00021A - 00021D
Array member 4 expected unit address 00021E - 000221
Array member 4 current unit address 000222 - 000225
Array member 5 type 000226 - 000229
Array member 5 serial number 00022A - 00022D
Array member 5 expected unit address 00022E - 000231
Array member 5 current unit address 000232 - 000235
Array member 6 type 000236 - 000239
Array member 6 serial number 00023A - 00023D
Array member 6 expected unit address 00023E - 000241
Array member 6 current unit address 000242 - 000245
Array member 7 type 000246 - 000249
Array member 7 serial number 00024A - 00024D
Array member 7 expected unit address 00024E - 000251
Array member 7 current unit address 000252 - 000255
Array member 8 type 000256 - 000259
Array member 8 serial number 00025A - 00025D
Array member 8 expected unit address 00025E - 000261
Array member 8 current unit address 000262 - 000265
Array member 9 type 000266 - 000269
Array member 9 serial number 00026A - 00026D
Array member 9 expected unit address 00026E - 000271
Array member 9 current unit address 000272 - 000275
Table 11. Format 03
Description Hex offset
Current I/O card type 0001C6 - 0001C7
Current I/O card serial number 0001CA - 0001CD
Current cache type 0001CE - 0001CF
Current cache serial number 0001D2 - 0001D5
Expected I/O card type 0001D6 - 0001D7
Expected I/O card serial number 0001DA - 0001DD
Expected cache type 0001DE - 0001DF
Expected cache serial number 0001E2 - 0001E5
Common service procedures 41
