Table 12. Format 04
Description Hex offset
Array member 10 type 0001B6 - 0001B9
Array member 10 serial number 0001BA - 0001BD
Array member 10 expected unit address 0001BE - 0001C1
Array member 10 current unit address 0001C2 - 0001C5
Array member 11 type 0001C6 - 0001C9
Array member 11 serial number 0001CA - 0001CD
Array member 11 expected unit address 0001CE - 0001D1
Array member 11 current unit address 0001D2 - 0001D5
Array member 12 type 0001D6 - 0001D9
Array member 12 serial number 0001DA - 0001DD
Array member 12 expected unit address 0001DE - 0001E1
Array member 12 current unit address 0001E2 - 0001E5
Array member 13 type 0001E6 - 0001E9
Array member 13 serial number 0001EA - 0001ED
Array member 13 expected unit address 0001EE - 0001F1
Array member 13 current unit address 0001F2 - 0001F5
Array member 14 type 0001F6 - 0001F9
Array member 14 serial number 0001FA - 0001FD
Array member 14 expected unit address 0001FE - 000201
Array member 14 current unit address 000202 - 000205
Array member 15 type 000206 - 000209
Array member 15 serial number 00020A - 00020D
Array member 15 expected unit address 00020E - 000211
Array member 15 current unit address 000212 - 000215
Array member 16 type 000216 - 000219
Array member 16 serial number 00021A - 00021D
Array member 16 expected unit address 00021E - 000221
Array member 16 current unit address 000222 - 000225
Array member 17 type 000226 - 000229
Array member 17 serial number 00022A - 00022D
Array member 17 expected unit address 00022E - 000231
Array member 17 current unit address 000232 - 000235
Table 13. Format 11
Description Hex offset
SCSI sense data 0001C4 - 0001E3
Worldwide ID of device with problem 0001E4 - 001EB
Unit address of device with problem 0001EC - 0001EF
SCSI command descriptor block 0001F4 - 000203
Problem description 000204 - 000223
