Fibre Channel
System component Description
Fibre Channel ports 48 SFP+ ports that support any combination of Short Wavelength (SWL) and
Long Wavelength (LWL) or Extended Long Wavelength (ELWL) optical media.
4 QSFP ports that support 32-Gbps QSFP transceivers.
The SFP+ ports are capable of auto-negotiating to 4, 8, 16, or 32 Gbps speed
depending on the SFP+ model and the minimum supported speed of the
optical transceiver at the other end of the link.
• 4-, 8-, and 16-Gbps performance is enabled by 16-Gbps SFP+ transceivers
provided the other end of the connection is minimum of 4 Gbps speed.
• 8-, 16-, and 32-Gbps performance is enabled by 32-Gbps SFP+
transceivers provided the other end of the connection is minimum of 8 Gbps
speed.
Note: 2- and 4-Gbps transceivers are not supported.
ANSI Fibre Channel
protocol
FC-PH (Fibre Channel Physical and Signaling Interface standard)
Modes of operation Fibre Channel Class 2 and Class 3
Fabric initialization Complies with FC-SW-3 Rev. 6.6
FCIP (IP over Fibre
Channel)
Complies with FC-IP 2.3 of FCA prole
Port Status Bicolor LED (amber/green)
Other
System component
Description
Serial console port One three-wire (Tx, Rx, Gnd) UART serial port
Ethernet management
port
One 1000Base-X / 100Base-TX port / 10Base-T
USB port One external USB port
LEDs
System component
Description
System power LED One green system power status LED (upper) on the port side.
System status LED One bicolor (green/amber) system status LED (lower) on the port side.
Ethernet port link LED One link LED on the left of the RJ45 connector. Glows green for 1000 Mbps
and amber for 100/10 Mbps.
Ethernet port activity
LED
One activity LED on the right of the RJ45 connector.
82 IBM Storage Networking SAN64B-6: SAN64B-6 Installation, Service, and User Guide
