System component Description
Serial console port LED The serial console port LEDs remain off at all times, even when a cable is
inserted and the link is active.
FC port status LED 64 bicolor (green/amber) port status LEDs. One for each SFP+ port and four
for each QSFP port on the switch.
Power supply and fan
assembly status LED
One green power supply and fan assembly status LED on each power supply
and fan assembly on the nonport-side of the switch.
Other
System component Description
Serial cable RJ-45 console cable
RJ-45 to DB9 adapter RJ-45 to DB9 for console cable
RJ-45 connector Uses an RJ-45 connector for the serial port
Weight and physical dimensions
Empty weight refers to the device with two power supply and fan assemblies installed but no SFP+ or
QSFP transceivers.
Model
Height Width Depth Weight
(empty)
Weight (fully
loaded)
SAN64B-6
switch
4.39 cm
1.73 inches
44.00 cm
17.32 inches
35.56 cm
14.00 inches
7.71 kg
17.00 lb
8.53 kg
18.80 lb
Environmental requirements
Condition
Operational Non-operational
Ambient
temperature
0°C to 40°C (32°F to 104°F) -25°C to 70°C (-13°F to 158°F)
Relative humidity
(non-condensing)
10% to 85% at 40°C (104°F) 10% to 90% non-condensing
Altitude (above sea
level)
0 to 3000 m (9,842 feet) 0 to 12000 m (39,370 feet)
Shock 20.0 G, 6 ms, half-sine wave 33.0 G, 11 ms, half-sine wave, 3G Axis
Vibration 0.25 G sine, 0.4 gms random, 5 –
500 Hz
5Hz at 0.5grms, 10-500Hz at 1.0grms
(sine vibration); 3-500Hz at 1.12grms
(random vibration)
Airflow Maximum: 71.36 cmh (42 cfm)
Nominal: 59.47 cmh (35 cfm)
N/A
Appendix A. Product specications 83
