IBM SAN64B-6 User Manual

Port speed
(Gbps)
Cable size
(microns)
Short wavelength
(SWL)
Long wavelength
(LWL)
Extended long
wavelength (ELWL)
8 50 50 m (164 ft) (OM2)
150 m (492 ft) (OM3)
190 m (623 ft) (OM4)
N/A N/A
62.5 21 m (68 ft) N/A N/A
9 N/A 10 km (6.2 miles) N/A
10 50 82 m (269 ft) (OM2)
300 m (984 ft) (OM3)
550 m (1,804 ft) (OM4)
N/A N/A
62.5 33 m (108 ft) N/A N/A
9 N/A 10 km (6.2 miles) N/A
16 50 35 m (115 ft) (OM2)
100 m (328 ft) (OM3)
125 m (410 ft) (OM4)
N/A N/A
62.5 15 m (49 ft) N/A N/A
9 N/A 10 km (6.2 miles) N/A
32 50 70 m (230 ft) (OM3)
100 m (328 ft) (OM4)
N/A N/A
62.5 N/A N/A N/A
9 N/A 10 km (6.2 miles) N/A
Serial port specications (pinout RJ-45)
Pin
Signal Description
1 Not supported N/A
2 Not supported N/A
3 UART1_RXD Receive data
4 GND Logic ground
5 GND Logic ground
6 UART2_TXD Transmit data
7 Not supported N/A
86 IBM Storage Networking SAN64B-6: SAN64B-6 Installation, Service, and User Guide
