• The illustrations for this procedure show a two-post rack with narrow posts (3- to 5-inch) as an
example.
• The illustrations in the rack installation procedures are for reference only and may not show the actual
device.
CAUTION: Use the screws specied in the procedure. Using longer screws can damage the device.
Complete the following tasks to install the device in a rack:
1. “Attaching the front brackets to the device” on page 27
2. “Attaching the front brackets to the rack” on page 28
3. “Attaching the rear brackets to the rack” on page 29
4. “Attaching the rear brackets to the device” on page 30
Attaching the front brackets to the device
About this task
Complete the following steps to attach the front brackets to the device.
Procedure
1. Position the right front bracket with the flat side against the right side of the device, as shown in Figure
17 on page 28.
2. Insert four 8-32 x 5/16-in. flathead screws through the vertically aligned holes in the bracket and then
into the holes on the side of the device. Use the upper and lower screw holes, leaving the center holes
empty.
3. Repeat step “1” on page 27 and step “2” on page 27 to attach the left front bracket to the left side of
the device.
4. Tighten all the 8-32 x 5/16-in. screws to a torque of 15 in-lb (17 cm-kg).
Chapter 3. Mounting the switch
27
