About this task
This task assumes that the following conditions are met:
v You removed the PSU, following the procedure described in “Removing a power
supply: 2077-92F” on page 103.
v You removed the fascia that covers the PSU from the front of the expansion
enclosure, as described in “Removing the fascia: 2077-92F” on page 85.
v You are aware of the procedures for handling static-sensitive devices.
Procedure
1. Read all safety information.
2. Rotate the handles on the PSU outward, as shown in Figure 70.
3. Slide the PSU forward into the chassis until it clicks in to place, as shown in
Figure 71 on page 84.
svc01011
Figure 70. Preparing to install the power supply
Chapter 2. Installing the system hardware 83

IBM Storwize V5000 Gen2 Specifications

General

Model	Storwize V5000 Gen2
Storage Type	Hybrid Flash Array
Form Factor	2U
Maximum Drives	240
Operating System	IBM Spectrum Virtualize
Drive Types	SSD
RAID Levels	0, 1, 5, 6, 10
Host Interface	8 Gbps Fibre Channel (FC), 16 Gbps Fibre Channel (FC), 10 Gbps iSCSI, 12 Gbps SAS
Drive Bays	24
Cache Memory	Up to 64 GB
Power Supply	Redundant, hot-swappable power supplies
Virtualization	Yes
