Table 14. Weight of expansion enclosure parts (continued)
FRU
description
FRU part
number
Weight per unit
Quantity
shipped
Total weight
kg lbs kg lb
Top cover 01LJ132 3.720 8.201 1 3.720 8.201
Fan interface
board
01LJ134 0.118 0.260 1 0.236 0.260
Weight of expansion enclosure SAS drives
The SAS drives are shipped in a separate package from the 2077-92F expansion
enclosure. The enclosure can support up to 92 SAS drives; however, the quantity
varies depending on the number of drives ordered.
Table 15 summarizes the weight of the SAS drives in a 2077-92F expansion
enclosure. All Storwize V5000 Gen2 systems that are running software level 7.8 can
support the 2077-92F expansion enclosure.
Table 15. Weight of expansion enclosure drives
FRU description FRU part number Feature code Comments
Approximate weight per unit
kg lb
600 GB 15 K
2.5-inch hard disk
drive
01LJ037 ACP0 Common to all
Storwize V5000
Gen2 systems.
0.304 0.670
1.2 TB 10 K
2.5-inch hard disk
drive
01LJ038 ACP3 0.304 0.670
1.8 TB 10 K
2.5-inch hard disk
drive
01LJ039 ACP4 0.304 0.670
6 TB 7.2 K
3.5-inch
Near-Line SAS
hard disk drive
01LJ040 ACP7 0.876 1.931
8 TB 7.2 K
3.5-inch
Near-Line SAS
hard disk drive
01LJ041 ACP8 0.876 1.931
10 TB 7.2 K
3.5-inch
Near-Line SAS
hard disk drive
01LJ042 ACP9 0.876 1.931
1.6 TB 2.5-inch
tier 0 flash drive
01LJ043 ACPD For systems with
a 1-year warranty
(2077-xxx).
0.224 0.494
1.6 TB 2.5-inch
tier 0 flash drive
ACQD For systems with
a 3-year warranty
(2078-xxx).
0.224 0.494
Chapter 2. Installing the system hardware 37
