Before you begin
CAUTION:
33.6-46.3 kg (74-102 lbs) 46.3-61.7 kg (102-136 lbs)
61.7-100 kg (136-220 lbs)
>
_
svc01053
The weight of this part or unit is more than 55 kg (121.2 lb). It takes specially
trained persons, a lifting device, or both to safely lift this part or unit. (C011)
CAUTION:
To avoid personal injury, before lifting this unit, remove all appropriate
subassemblies per instructions to reduce the system weight. (C012)
Important: Before you unpack, move, install, or service the 2077-92F expansion
enclosure and its parts, always complete the following tasks:
v Read and follow the safety notices and instructions, as described in “Safety
notices and considerations: 2077-92F” on page 29.
v Read and follow the guidelines that are described in “Weight considerations:
2077-92F” on page 35.
v Ensure that a suitably rated mechanical lift is available to support the weight of
the expansion enclosure as it inserted into the rack for installation.
About this task
The 2077-92F expansion enclosure and most parts are shipped together in one large
box. A tray on the top of the enclosure contains the front fascia (1U and 4U pieces),
the cable management arm (CMA), and the slide rail kit; you must install these
parts. Figure 27 shows how the enclosure is packaged for shipment.
Figure 27. Tray containing expansion enclosure parts
Chapter 2. Installing the system hardware 45
