Removing the top cover

To remove the top cover:

1. Locate the metal holding clip located in the rear center of the top cover (C in

Figure 21).

2. Push this clip downward and push the cover backward a few inches, then lift

upward to remove.

Figure 21. Removing the top cover

34 SurePOS 700-723/743/783/784 Hardware Service Guide
