Replacing the system board battery (Models xx4)
The following picture shows the location of the system board battery A for Models
xx4. To remove the battery, grasp it with the thumb and index finger, and lift up.
Reverse this procedure to install the battery.
A
Figure 40. Replacing the Model xx4 battery
Chapter 2. Removal and replacement procedures 55
