Page #17 background imageLoading...
Page #17 background image
3.
Count
specified
in
the
CCW
is
zero.
4.
Data
address
specified
by
the
CCW
exceeds
the
storage
size.
5.
Command
address
specified
by
the
CCW
ex-
ceeds
the
storage
size.
6. CCW
sequence
in
which
the
first
CCW
speci-
fied
by
the
command
address
word
is
a
transfer
in
channel.
7. CCW
sequence
in
which
two
successive
CCW' s
specify
transfer
in
channel.
8.
Command
address
specified
in
the
CCW
is
not
on a
doubleword
boundary.
9.
Command
address
word
in
which
positions
4-7
are
not
zero.
The
following
condition
will
cause
a
protection
check:
1.
The
storage-ptotect
tag
specified
in
the
com-
mand
address
word
does
not
agree
with
the
key of
the
addressed
area
of
storage
during
a
data
store.
The
following
conditions
will
cause
a
chaining
check:
1.
The
channel
accepts
more
than one
byte
of
read
data
assembling
on
word
boundaries
when
the
CCW
specifies
byte
boundaries
on
data
chaining.
This
is
detected
in
the
CCW 1
routine.
2.
The
channel
accepts
more
bytes
than
CCW
specifies
while
data
chaining.
This
is
detected
in
the
CCW 2
routine.
Note: Both
of
the
foregoing
conditions
are
caused
by
attempting
to
read
data
chain
with a
control
unit
whose
data
rate
is
faster
than
the
maximum
speci-
fied
in
the
Field
Engineering
Theory
of
Operation
Manual,
Model 50
Functional
Units, SY22-2822.
Mode Switch
Settings
Stop Mode:
The
system
is
not
stopped
and
a
master
check
does
not
occur.
If
the
system
is
not
masked,
an
I/O
interrupt
occurs.
If
error
occurred
during
an
initiation
of
a new
I/O
instruction,
logout
takes
place
and a
CSW
is
stored.
Channel
Stop Mode:
The
system
is
stopped
by a
log
request
in
the
check
register
and
a
master
check.
The
channel
indicators
remain
unchanged.
Process
or
Disable
Mode:
Same
as
for
stop
mode.
Data
Check
The
following
conditions
will
cause
a
data
check:
1.
A
parity
check
on
'bus
in'
while
reading
data
into
the
channel.
The
parity
is
corrected
before
the
data
is
set
into
the
c-register.
2. A
parity
check
is
detected
on
write
data
going
to
'bus
out'.
The
parity
is
not
corrected.
16
(3/71)
Model
50
FEMM
Mode
Switch
Settings
Process
or
Disable
Mode: Channel
proceeds
to
end
of
record;
when
channel
is
not
masked
an
I/O
inter-
rupt
occurs.
Stop
or
Channel
Stop Mode:
The
channel
stops.
A
~a~ter
c;hec!<
an.d
log
request
(CPU
roller
2,
position
6)
are
displayed.
SIM
Check
This
check
.indicator
informs
the
channel
to
terminate
an
operation.
It
indicate$
that
control
unit
status
is
not
available
for
the
CSW.
SIM
check
occurs
only
inside
the
channel
and
never
appears
in
the
CSW.
The
following
conditions
set
SIM check:
1.
Channel
detects
an
error
before
the
control
unit
can
be
selected
to
perform
an
operation.
2..
A
halt
I/O
instruction
terminates
the
current
operation.
3.
An
interface
selective
reset
caused
by an
inter-
face
control
check
occurring.in
disable
mode.
Incorrect
Lengthlndication
(ILI)
This
indication
appears
in
the
CSW
and
will
suppress
command
chaining
unless
the
suppress
incorrect
length
indication
(SIL!)
flag
is
present
in
the
current
CSW. If
the
current
CCW
has
a
data
chain
and a
SIL! flag,
the
indication
is
not
suppressed
and will
appear
in
the
CSW.
The
indication
cannot
occur
on a
command
im-
mediate.
When the
channel
pref
etches
an
invalid
CC W
(storage-protect
or
program
check) on a
write
data
chain
operation
and
the
control
unit
sends
status
in
before
the
count
in the
cu.rrent
CCW
is
exhausted.
the
ILi
indication
will
suppress
the
storage
-protect
or
program
check
condition.
This
is
also
true
if
the
channel
prefetches
data
with an
invalid
data
address.
The
ILI
indication
cannot
appear
in
the
CSW
as
a
re-
sult
of a
program
controlled
interrupt
(PCI) flag.
ILi
is
turned
on by
the
following conditions:
1. A
control
unit
sends
service
in
one
or
more
times
after
the
count in
the
CCW
has
been
exhausted.
On a
read
operation
the
extra
bytes
are
not
placed
in
main
storage.
An
extra
service
in
almost
always
occurs
on a
write
or
control
operation.
the
only
ex-
ception
being
on a
formatted
type
device
with a
fixed
record
length.
The
residual
count
in
the
CSW
is
zero.
2.
Service
in
is
sent
by
a
control
unit
less
times
than
specified
by the CCW.
The
residual
count in
the
CSW
is
not
zero.
