PCI riser-card adapter connectors
The following illustration shows the connectors on the PCI riser card for
user-installable PCI adapters.
PCI
riser-card
assembly
Adapter
Adapter
connectors
PCI riser-card assembly LEDs
The following illustration shows the light-emitting diodes (LEDs) on the PCI
riser-card assembly.
Note: Error LEDs remain lit only while the server is connected to power.
Upper PCI slot error LED
(Adaptor card error LED)
Lower PCI slot
error LED
36 System x3650 M3 Types 4255, 7945, and 7949: Installation and User’s Guide
