When installing the antenna assembly, do as follows:
1. Attach the antenna and route the cable.
Note: Attach the gray cable (MAIN) to the left side and
the black cable (AUX) to the right side of the
LCD cover.
2. Secure the cables with insulation tape in the order
shown 1 and 2.
12
(continued)
Removing and replacing a FRU
ThinkPad A30, A30p 125
