1070 Ultrabay Plus device
Note
Ultrabay Plus does not support Ultrabay 2000
battery. For supported devices, see “Optional FRUs”
on page 153. The procedure for installing and
removing is the same for every device.
Note: When you release the switch in step 1 the lever
pops out. Pull the lever a little in step 2 to release
the device from the bay.
1
2
3
Removing and replacing a FRU
74 ThinkPad A30, A30p (MT 2652/2653/2654)
