Bluetooth daughter card
Following illustrations show the combination of the MiniPCI
combo (modem/wireless LAN) card, Ethernet daughter
card, and Bluetooth daughter card.
4
3
3
Step Screw (quantity) Torque
3 CDC screw (2) 0.392 Nm
(4 kgfcm)
6
5
When installing:
1. Make sure that the connector 4is firmly attached.
2. Plug the white cable with the tab marked “BT” into the
jack on the Bluetooth daughter card.
Removing and replacing a FRU
68 ThinkPad A30, A30p (MT 2652/2653/2654)
