IBM ThinkPad A30

1110 Keyboard bezel
For access, remove these FRUs, in order:
v “1010 Battery pack” on page 59
v “1070 Ultrabay Plus device” on page 74
v “1080 Ultrabay 2000 device” on page 75
v “1090 Keyboard” on page 76
v “1100 Keyboard CRU insulator” on page 80
1
1
1
1
Step Screw (quantity) Torque
1 M2.5 × 16 mm, nylon-coated (4) 0.392 Nm
(4 kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad A30, A30p 81
