Using Locks
Note:
This also prevents the removal of:
Internal devices under the
keyboard
Memory modules (DIMMs) in the
memory slot on the bottom of the
computer.
2
Attach a Kensington lock or a compatible lock to the keyhole
on the side of the computer; then secure the chain on the lock
to a secure stationary object.
Using the PC Card Lock
To prevent PC Cards from being removed from the PC Card slots:
Attention:
Make sure the security latch at the
right side of the computer is
unlocked. (See step 2 on page 7.)
Attention:
The hard disk drive is a very delicate
device that needs careful handling.
If it falls onto a hard surface, severe
damage can occur.
1
Open the keyboard and remove the hard disk drive; then
position the PC Card lock as shown.
118 IBM ThinkPad 760E, 760ED, or 760EL User's Guide
