Installing a Secondary Battery Pack in the UltraBay
5
Pinch together both holes and remove the spacer by lifting it up
slightly.
1
2
6
Place the spacer to cover the CD-ROM drive or diskette drive
connector.
a) Make sure the projected end 1 fits into the opening 2 .
1
2
b) Place the spacer onto the connector and then open the
battery connector cover.
7
Which drive are you removing?
CD-ROM drive Go to step 8 on page 140.
Diskette drive Go to step 10 on page 140.
Chapter 6. Installing and Removing Options 139
