Installing a Secondary Battery Pack in the UltraBay
11
Place the blank bezel at position 1 as shown and slide it to
the right.
1
12
Insert the secondary battery pack into the UltraBay.
1
2
13
Close the keyboard and reconnect all cables.
When Replacing the CD-ROM Drive or Diskette Drive
Before you replace the CD-ROM drive or diskette drive in the
UltraBay:
1. Cover the battery connector with its cover.
2. Move the spacer back to its original position (shown in step 5
on page 139).
Chapter 6. Installing and Removing Options 141
