3
2
3
a
a
b
a
Step Screw (quantity) Color Torque
2 M2 × 4 mm, bind-head,
nylon-coated (1)
Black 0.245 Nm
(2.5 kgfcm)
In step 3, make sure that all the latches marked a are
detached, and then remove the bezel.
When installing: Make sure that all the latches marked
a are firmly attached. Attach herness
left (b), and then secure the keyboard
bezel with the screws.
Removing and replacing a FRU
ThinkPad T40, T40p, T41 Series 97
