1090 Palm rest
For access, remove these FRUs in order:
v “1010 Battery pack” on page 68
v “1030 Hard disk drive” on page 71
v “1050 Keyboard” on page 75
Note: For some models, this FRU is secured by using a
tamper resistant torx head screw (TR7).
3a
3
1
1
1
1
2
Step Icon Screw
cap
Screw (quantity) Color Torque
1
1
M2 × 4 mm,
small-head,
nylon-coated (4)
Black 0.245 Nm
(2.5 kgfcm)
2
2
M2 × 5 mm,
bind-head,
nylon-coated (1)
Silver 0.245 Nm
(2.5 kgfcm)
3 Models with a 802.11b wireless LAN Mini PCI adapter
4
— M2 × 14 mm,
bind-head,
nylon-coated (2)
Black 0.204 Nm
(2.0 kgfcm)
Models with a 802.11a/b wireless LAN Mini PCI adapter
4
— M2 × 14 mm, TR7,
nylon-coated (2)
Black 0.204 Nm
(2.0 kgfcm)
3a
4
— Special screw (1) Black 0.245 Nm
(2.5 kgfcm)
(continued)
