1100 Mini PCI adapter
For access, remove these FRUs in order:
v “1010 Battery pack” on page 68
v “1030 Hard disk drive” on page 71
v “1050 Keyboard” on page 75
v “1090 Palm rest” on page 84
Note: When unplugging the antenna jack, do not pull the
cable; it might snap. Unplug the jack by pulling the
tab with your fingers.
1
2
3
3
4
Removing and replacing a FRU
86 MT 2373/2374/2375/2376/2378/2379
