1070 Modem daughter card (MDC)
For access, remove these FRUs in order:
v “1010 Battery pack” on page 68
v “1050 Keyboard” on page 75
2
1
1
Step Screw (quantity) Color Torque
1 M2 × 10 mm, flat-head,
nylon-coated (2)
Black 0.245 Nm
(2.5 kgfcm)
In step 2, remove the card by pulling the tab with your
fingers in the direction of the arrow.
(continued)
Removing and replacing a FRU
80 MT 2373/2374/2375/2376/2378/2379
