IBM ThinkPad T40 series

1180 Ultrabay Slim guide rail assembly
For access, remove these FRUs in order:
v “1010 Battery pack” on page 68
v “1030 Hard disk drive” on page 71
v “1050 Keyboard” on page 75
v “1090 Palm rest” on page 84
v “1130 Speaker assembly” on page 92
v “1140 PC Card slot assembly” on page 94
v “1150 Keyboard bezel” on page 96
v “1160 LCD assembly” on page 98
1
2
Step Screw (quantity) Color Torque
1 M2 × 14 mm, bind-head,
nylon-coated (1)
Black 0.204 Nm
(2.0 kgfcm)
2 M2 × 4 mm, bind-head,
nylon-coated (1)
Black 0.204 Nm
(2.0 kgfcm)
(continued)
Removing and replacing a FRU
104 MT 2373/2374/2375/2376/2378/2379
