Turn the card over 3, and detach the modem connector
4 and the Bluetooth wireless antenna jack, which has a
tab marked BT 5.
Note: When unplugging the Bluetooth wireless antenna
jack, do not pull the cable; it might snap. Unplug the
jack by pulling the tab with your fingers.
3
4
5
When installing: Make sure that connector 4, the jack
5, and the connector on the underside
of the card are firmly attached.
Removing and replacing a FRU
ThinkPad T40, T40p, T41 Series 83
