IBM ThinkPad T40 series Hardware Maintenance Manual

No. FRU P/N CRU
ID
15 System board assembly, ATI M7-32,
Gigabit Ethernet
v Supported by CTO
91P7713 N
System board assembly, ATI M7-32,
Gigabit Ethernet with security chip
v 2373-32x, 42x, 47x, 49x, 4Ax, 72x, 75x,
82x, 85x, 8Dx, A2x, A4x, B2x, B5x,
BDx, C3x, C7x, CAx
v 2374-72x, 75x, 82x
v 2375-72x
v 2376-72x
91P7716 N
System board assembly, ATI M9-32,
Gigabit Ethernet with security chip
v 2373-33x, 58x, 91x, 92x, 93x, 94x, 96x,
9Cx, A1x, A8x
v 2374-9Cx
v 2379-D5x, D6x
91P7719 N
System board assembly, ATI M9 GL-64,
Gigabit Ethernet with security chip
v 2373-G1x, G2x, G3x, G4x, G5x, G6x,
A9x
91P7722 N
System board assembly, ATI M7-32,
Gigabit Ethernet with security chip
v 2373-1Ex, 1Fx, 1Hx, 1Lx, 2Ex, 2Fx,
2Qx, 2Rx, 3Fx, 3Px, 4Fx, 4Gx, 4Hx,
4Nx, 4Px, 4Qx, 4Sx, 5Hx, 5Qx, 5Rx,
6Kx, 6Sx, 7Ex, 7Fx, 7Jx, 7Kx, 7Mx,
7Px, 8HU, 8Jx, 8Kx, 8Px, 8Rx, 8Sx,
AFx, AHx, AJx, AKx, ALx, BFx, BHx,
BJx
v 2374-1Fx, 1Hx, 2Rx, 4Hx, 7Fx, 7Jx,
8Rx
v 2378-DFx, DGx, DHx, EFx, EHx, EJx,
EKx, ELx, EMx
v 2379-DKx, ERx
91P7370 N
System board assembly, ATI M9-32,
Gigabit Ethernet with security chip
v 2373-3Hx, 9Ex, 9Fx, 9Gx, 9Hx, 9Jx,
9Kx, 9Px, 9Rx, AMx, AEx
v 2374-3Hx, 9Px, 9Rx
v 2378-DEx, EEx, ENx, EPx
v 2379-DJx, ESx
91P7371 N
(continued)
Parts list
ThinkPad T40, T40p, T41 Series 163

IBM ThinkPad T40 series Specifications

General

Processor	Intel Pentium M (1.3 GHz - 1.7 GHz)
Chipset	Intel 855PM
Hard Drive Interface	ATA-100
Modem	56K V.92
Release Year	2003
RAM	256 MB - 2 GB (DDR SDRAM)
Storage	30 GB - 80 GB (HDD)
Display	14.1"
Graphics	ATI Mobility Radeon 7500 or 9000
Optical Drive	DVD-ROM/CD-RW Combo
Operating System	Windows XP Professional
Weight	2.2 kg (4.9 lbs)
Battery	Li-Ion
Wireless	Intel PRO/Wireless 2100
Ethernet	10/100 Mbps
Ports	2 x USB 2.0, VGA, RJ-11, RJ-45, Audio In/Out
Dimensions	311 mm x 255 mm x 26.6 mm (12.24" x 10.04" x 1.05")
