IBM ThinkPad T40 series Hardware Maintenance Manual

Symptom or error FRU or action, in sequence
02F4
EISA CMOS not writable.
1. Load Setup Defaults in
IBM BIOS Setup Utility.
2. Replace the backup battery.
3. System board.
02F5
DMA test failed.
1. DIMM.
2. System board.
02F6
Software NMI failed
1. DIMM.
2. System board.
02F7
Fail-safe timer NMI failed
1. DIMM.
2. System board.
1802
Unauthorized network card is
plugged in—Turn off and
remove the miniPCI network
card.
1. Remove Mini PCI network
card.
2. System board.
1803
Unauthorized daughter card is
plugged in—Turn off and
remove the daughter card.
1. Remove the daughter
card that you installed.
2. System board.
Symptom-to-FRU index
58 MT 2373/2374/2375/2376/2378/2379

IBM ThinkPad T40 series Specifications

General

Processor	Intel Pentium M (1.3 GHz - 1.7 GHz)
Chipset	Intel 855PM
Hard Drive Interface	ATA-100
Modem	56K V.92
Release Year	2003
RAM	256 MB - 2 GB (DDR SDRAM)
Storage	30 GB - 80 GB (HDD)
Display	14.1"
Graphics	ATI Mobility Radeon 7500 or 9000
Optical Drive	DVD-ROM/CD-RW Combo
Operating System	Windows XP Professional
Weight	2.2 kg (4.9 lbs)
Battery	Li-Ion
Wireless	Intel PRO/Wireless 2100
Ethernet	10/100 Mbps
Ports	2 x USB 2.0, VGA, RJ-11, RJ-45, Audio In/Out
Dimensions	311 mm x 255 mm x 26.6 mm (12.24" x 10.04" x 1.05")
