IBM ThinkPad X30, ThinkPad X31 (MT 2672

2030 LCD panel
For access, remove following FRUs, in order:
v “1010 Battery pack” on page 71
v “1020 Hard-disk drive” on page 72
v “1030 DIMM cover” on page 74
v “1040 DIMM” on page 75
v “1050 Backup battery” on page 76
v “1060 Keyboard” on page 77
v “1100 Keyboard bezel” on page 98
v “1120 Hinge cover and LCD assembly” on page 104
v “2010 LCD front bezel” on page 116
v “2020 Inverter card” on page 117
For models with no wireless LAN antenna
1
1
1
1
1
1
Step Screw (quantity) Torque
1 M2 × 4 mm, nylon-coated (6) 0.245 Nm
(2.5 kgfcm)
(continued)
Removing and replacing a FRU
ThinkPad X30, X31 119
