1020 Hard-disk drive
Attention
v Do not drop or apply any shock to the
hard-disk drive. The hard-disk drive is sensitive
to physical shock. Incorrect handling can cause
damage and permanent loss of data.
v Before removing the drive, have the user make a
backup copy of all the information on the drive if
possible.
v Never remove the drive while the system is
operating or is in suspend mode.
For access, remove following FRU:
v “1010 Battery pack” on page 71
1
Note: The hard disk is attached to the cover.
Step Screw (quantity) Torque
1 M3 × 4 mm, nylon-coated (1) 0.4 Nm
(4 kgfcm)
(continued)
Removing and replacing a FRU
72 ThinkPad X30, X31 (MT 2672/2673)
