IBM ThinkPad X30, ThinkPad X31 (MT 2672

1080 Fan assembly
For access, remove following FRUs, in order:
v “1010 Battery pack” on page 71
v “1020 Hard-disk drive” on page 72
v “1060 Keyboard” on page 77
1
1
1
Step Screw (quantity) Torque
1 M2 × 9.5 mm, nylon-coated (5) 0.245 Nm
(2.5 kgfcm)
For X30 series
2
3
(continued)
Removing and replacing a FRU
ThinkPad X30, X31 89
