v Handle the device carefully, holding it by its edges or its frame.
v Do not touch solder joints, pins, or exposed circuitry.
v Do not leave the device where others can handle and damage it.
v While the device is still in its static-protective package, touch it to an unpainted
metal part of the server for at least 2 seconds. This drains static electricity from
the package and from your body.
v Remove the device from its package and install it directly into the server without
setting down the device. If it is necessary to set down the device, put it back into
its static-protective package. Do not place the device on the server cover or on a
metal surface.
v Take additional care when handling devices during cold weather. Heating reduces
indoor humidity and increases static electricity.
Removing the bezel
Important: Before you install optional hardware, make sure that the server is
working correctly. Start the server, and make sure that the operating system starts,
if an operating system is installed, or that a 19990305 error code is displayed,
indicating that an operating system was not found but the server is otherwise
working correctly. If the server is not working correctly, see the Problem
Determination and Service Guide for diagnostic information.
The following illustration shows how to remove the bezel from the server.
Notes:
1. The left-side cover does not have to be removed to remove the bezel from the
server.
2. The left-side cover lock must be unlocked to open or remove the bezel.
Complete the following steps to remove the bezel:
1. Read the safety information that begins on page v and “Installation guidelines”
on page 21.
2. Using the supplied key, unlock the left-side cover and bezel.
Chapter 2. Installing optional devices 23
