1 - 1
SECTION 1 SPECIFICATIONS
All stated specifications are subject to change without notice or obligation.
M GENERAL
• Frequency range :
LEFT SIDE
RIGHT SIDE
*
1
Guaranteed 144.000 – 146.000 MHz only, *
2
Guaranteed 144.000 – 148.000 MHz only,
*
3
Guaranteed 430.000 – 440.000 MHz only; *
4
Guaranteed 440.000 – 450.000 MHz only
*
5
Not guaranteed range
• Mode : FM, AM (AM range is 118.0 – 135.995 MHz and Rx only for [USA] and [EXP].)
• Nomber of memory channel : 212 (including 2 call channels and 10 scan edges)
• Usable temperature range : –10˚C to +60˚C; +14˚F to +140˚F
• Frequency resolution : 5, 10, 12.5, 15, 20, 25, 30 and 50 kHz
• Frequency stability : ±10 ppm (–10˚C to +60˚C; +14˚F to +140˚F)
• Power supply requirement : 13.8 V DC ±15 % (negative ground)
• Current drain
(at 13.8 V DC) : Receive Standby (squelched) 1.2 A
Max. audio output 1.8 A
Transmit at VHF 50 W/UHF 35 W 12.0 A/11.0 A
• Antenna connector : SO-239 (50 Ω)
• DATA connector : Mini DIN 6 pin
• Dimensions : Controller 140(W)
×50(H)×27(D) mm; 5
1
⁄2(W)×1
31
⁄32(H)×1
1
⁄16(D) inch
(projections not included) Main unit 140(W)×40(H)×187(D) mm; 5
1
⁄2(W)×1
9
⁄16(H)×7
3
⁄8(D) inch
• Weight : Controller 150 g; 5.29 oz
Main unit 1.4 kg; 3.0 lb
M TRANSMITTER
• Output power : VHF 50 W/25 W/5 W (selectable)
UHF 35 W/25 W/5 W (selectable)
• Modulation system : Variable reactance frequency
• Maximum frequency deviation : ±5.0 kHz
• Spurious emissions : Less than –60 dB
• Microphone connector : 8-pin modular jack (600 Ω)
M RECEIVER
• Receive system : Double-conversion superheterodyne
• Intermediate frequency : 1st IF 38.85 MHz/46.05 MHz
(Left/right side band) 2nd IF 450 kHz/455 kHz
• Sensitivity : Less than 0.18 µV (at 12 dB SINAD)
• Squelch sensitivity : Less than 0.13 µV (at threshold)
• Selectivity : More than 12 kHz/–6 dB (Wide); More than 6 kHz/–6 dB (Narrow)
Less than 30 kHz/–60 dB (Wide); Less than 20 kHz/–60 dB (Narrow)
• Spurious and image rejection : More than 60 dB
• Audio output power
(at 13.8 V) : More than 2.4 W at 10% distortion with an 8 Ω load
• External speaker connector : 2-conductor 3.5(d) mm (
1
⁄8")/8 Ω
VERSION
[KOR]
[SEA]
[EXP]
[USA]
RX (MHz)
144.000–146.000, 430.000–440.000
136.000–179.995*
2
, 430.000–440.000
118.000–549.995*
2
118.000–549.995*
2,
*
4
TX (MHz)
144.000–146.000, 430.000–440.000
140.000–150.000*
2
, 430.000–440.000
136.000–174.000*
2
, 400.000–479.000*
3
144.000–148.000, 430.000–450.000*
4
VERSION
[KOR]
[SEA]
[EXP]
[USA]
RX (MHz)
144.000–146.000, 430.000–440.000
136.000–173.995*
2
, 430.000–440.000
118.000–179.995*
2
, 375.000–549.995*
3
810.000–999.990*
5
118.000–174.000*
2
, 375.000–549.995*
4
,
810.000–824.000*
5
, 849.000–869.000*
5
,
894.000–999.990*
5
TX (MHz)
144.000–146.000, 430.000–440.000
140.000–150.000*
2
, 430.000–440.000
136.000–174.000*
2
, 400.000–479.000*
3
144.000–148.000, 430.000–450.000*
4
