5 - 1
SECTION 5 PARTS LIST
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[FRONT UNIT]
DS1 5030002820 LCD LTA025A161A
W1 8900013940 CBL OPC-1447 (N=10, L=30)
W2 8900013990 CBL OPC-1445
EP1 880001670 UBD EX-2822 #01
L1 6190001561 S.COL CDRH5D18NP-101NC B 68.4/6.3
L2 6190001561 S.COL CDRH5D18NP-101NC B 34.6/5.2
L3 6200002041 S.COL NLV25T-101J B 30.7/10.4
L51 6190001561 S.COL CDRH5D18NP-101NC B 55.9/6.2
L53 6200002041 S.COL NLV25T-101J B 60.9/10.9
L101 6200001831 S.COL NLV32T-100J B 96/11.6
L151 6200001831 S.COL NLV32T-100J B 96/8.6
L152 6200001831 S.COL NLV32T-100J B 100.6/11.4
L251 6200003950 S.COL HF50ACC 322513-T B 145.9/44
L252 6200003950 S.COL HF50ACC 322513-T B 146/50.6
L301 6200002041 S.COL NLV25T-101J B 109.6/16.7
L302 6200005011 S.COL NLV25T-100J T 112.6/24
L303 6200002041 S.COL NLV25T-101J T 112/20.3
L306 6200003261 S.COL NLV32T-101J T 109.8/25.5
L307 6200002041 S.COL NLV25T-101J T 115.4/26.6
L309 6200002041 S.COL NLV25T-101J T 115.3/24
L310 6200002041 S.COL NLV25T-101J T 115.4/21.5
L312 6200002041 S.COL NLV25T-101J T 115.4/19
L313 6200002041 S.COL NLV25T-101J T 115.7/16.3
L505 6200005521 S.COL NLV25T-470J B 71.2/47.9
L506 6200005011 S.COL NLV25T-100J B 67.9/20.2
L507 6200005011 S.COL NLV25T-100J B 50.2/29
L508 6200005011 S.COL NLV25T-100J B 49.3/24.3
L509 6200005011 S.COL NLV25T-100J B 17.4/35.6
L601 6200002041 S.COL NLV25T-101J B 70.6/25.2
L602 6200005011 S.COL NLV25T-100J B 53.5/36.2
L603 6200005011 S.COL NLV25T-100J B 51/43.6
L604 6200005011 S.COL NLV25T-100J B 53.5/43.6
L605 6200005011 S.COL NLV25T-100J B 50.9/36.2
L651 6200002041 S.COL NLV25T-101J B 19.1/42.7
L701 6200002041 S.COL NLV25T-101J B 21.1/37.5
L702 6200002041 S.COL NLV25T-101J B 65.4/10.9
L703 6200002041 S.COL NLV25T-101J B 27.9/11.3
L801 6200005011 S.COL NLV25T-100J B 63.4/16.9
L802 6200002041 S.COL NLV25T-101J B 19.1/47.5
L851 6200003950 S.COL HF50ACC 322513-T B 33.2/17.2
L852 6200003950 S.COL HF50ACC 322513-T B 35/21.3
L853 6200002041 S.COL NLV25T-101J B 34.4/26.6
L854 6200002041 S.COL NLV25T-101J B 34.4/24.1
L855 6200003950 S.COL HF50ACC 322513-T B 36.4/17.2
R1 7030008141 S.RES ERA3YKD 224V (220 k
Ω
) B 33.4/9.6
R2 7030005671 S.RES ERA3YKD 393V (39 k
Ω
) B 33.4/11.6
R3 7030008051 S.RES ERA3YKD 184V (180 k
Ω
) B 42.6/6.4
R4 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 40.9/6.8
R5 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 40.9/7.7
R51 7030008141 S.RES ERA3YKD 224V (220 k
Ω
) B 49.7/10.8
R52 7030007911 S.RES ERA3YKD 563V (56 k
Ω
) B 48.5/10.8
R53 7030006561 S.RES ERA3YED 223V (22 k
Ω
) B 46.5/11.8
R54 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 47.9/8.4
R55 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 48.8/8.4
R201 7030010040 S.RES ERJ2GEJ-JPW B 109.6/38
R202 7030010040 S.RES ERJ2GEJ-JPW B 109.6/39
R251 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 136.5/49.6
R252 7030000300 S.RES MCR10EZHJ 220
Ω
B 133.9/47.3
R253 7030000300 S.RES MCR10EZHJ 220
Ω
B 142/50.8
R254 7030000300 S.RES MCR10EZHJ 220
Ω
B 133.9/49
R255 7030000300 S.RES MCR10EZHJ 220
Ω
T 143.2/50.7
R301 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 113.2/32
R302 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) T 114/30.4
R303 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) B 111/33.4
R304 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 111.9/33.4
R305 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
Ω
) B 113.2/32.9
R306 7030005120 S.RES ERJ2GEJ 102 X (1 k
Ω
) T 114.9/11
R307 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 111.3/8.4
R308 7030005230 S.RES ERJ2GEJ 334 X (330 k
Ω
) B 113.8/5.3
R309 7030005310 S.RES ERJ2GEJ 124 X (120 k
Ω
) B 112/5.3
R310 7030008010 S.RES ERJ2GEJ 123 X (12 k
Ω
) B 110.2/5.3
R521 7030008370 S.RES ERJ2GEJ 561 X (560
Ω
) B 60.8/46.1
R522 7030010040 S.RES ERJ2GEJ-JPW B 65.3/47.4
R523 7030010040 S.RES ERJ2GEJ-JPW B 65.4/48.7
R524 7030010900 S.RES ERJ3GEYJ 750 V (75
Ω
) B 63.1/48.9
R528 7030010040 S.RES ERJ2GEJ-JPW B 60.8/42.6
R529 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 58.6/43.8
R530 7030005080 S.RES ERJ2GEJ 823 X (82 k
Ω
) B 60.8/43.6
R531 7030009290 S.RES ERJ2GEJ 562 X (5.6 k
Ω
) B 76.3/42.9
R532 7030005050 S.RES ERJ2GEJ 103 X (10 k
Ω
) B 60.8/37.2
R533 7030010040 S.RES ERJ2GEJ-JPW B 56.5/32.3
R534 7030010040 S.RES ERJ2GEJ-JPW B 60.8/36
R536 7030010040 S.RES ERJ2GEJ-JPW B 62.6/29
R537 7030010040 S.RES ERJ2GEJ-JPW B 64.6/29
R538 7030010040 S.RES ERJ2GEJ-JPW B 66.6/29
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[DISPLAY UNIT]
IC1 6910016730 S.DCC XC9504B092ARN B 44.4/9.4
IC101 1180001071 S.IC TA7805F (TE16L, Q) B 90.3/6.9
IC151 1180002201 S.IC RN5RZ33BA-TR-F B 99.9/4.8
IC301 1110002751 S.IC TA75S01F (TE85R, F) B 113.8/7.5
IC506 1120003010 S.IC AN2533FH-V B 69/38.5
IC651 1110005420 S.IC BA15532F-E2 B 4.1/25.6
IC2003 1140013140 S.IC HD64338020SB68HV B 93/26.3
IC2007 1110005821 S.IC R3112N281A-TR-F B 108.7/46.9
Q1 1550000090 S.FET RSQ035P03TR B 39.4/9.8
Q51 1560001330 S.FET RSR025N03 B 52.1/10.6
Q301 1560001290 S.FET 2SK3065 T100 T 110.8/31.4
Q302 1590003520 S.TR BCR108T T 116.7/10.2
Q303 1590003530 S.TR BCR08PN T 113.1/11.5
Q651 1590001650 S.TR XP4601 (TX) B 10.6/28.8
Q652 1590001650 S.TR XP4601 (TX) B 11.1/20.6
Q653 1590001650 S.TR XP4601 (TX) B 10.6/26.2
Q654 1590001650 S.TR XP4601 (TX) B 11.1/17
Q701 1530002060 S.TR 2SC4081 T106 R T 19.1/50.3
Q721 1530002060 S.TR 2SC4081 T106 R T 22/5.8
Q741 1530002060 S.TR 2SC4081 T106 R T 94/50.1
Q761 1530002060 S.TR 2SC4081 T106 R T 104.2/50.1
Q771 1530002060 S.TR 2SC4081 T106 R T 18.4/25.1
Q781 1530002060 S.TR 2SC4081 T106 R T 5.3/23.6
Q802 1520000460 S.TR 2SB1132 T100 R B 58.8/21.6
Q2001 1590003520 S.TR BCR108T B 81.6/23.7
Q2002 1590003570 S.TR BCR183T B 81.2/30.1
D1 1790000970 S.DIO MA729 (TX) B 36.8/10.1
D51 1750000730 S.DIO MA2SD1000L B 51/8
D301 1790001250 S.DIO MA2S111-(TX) B 111/32
D302 1790001520 S.ZEN MA8075-L (TX) B 109.9/7.6
D601 1750000950 S.DIO MA732 (TX) B 51.5/40
D602 1750000950 S.DIO MA732 (TX) B 53.3/40
D801 1730002340 S.ZEN MA8047-M (TX) B 35/40.4
D802 1730002340 S.ZEN MA8047-M (TX) B 39.8/25.8
D803 1730002340 S.ZEN MA8047-M (TX) B 38.6/22
D804 1730002340 S.ZEN MA8047-M (TX) B 41.8/23
D2001 1750000950 S.DIO MA732 (TX) T 107.4/26.5
D2002 1790001670 S.DIO RB706F-40T106 B 76.6/16.8
D2003 1790001670 S.DIO RB706F-40T106 T 116.4/36.7
D2004 1750000370 S.DIO DA221 TL T 100.6/41.8
D2005 1750000370 S.DIO DA221 TL B 101.7/42.8
D2006 1750000370 S.DIO DA221 TL B 107.3/5.9
X501 6050012140 S.XTL CR-805 [USA] B 87/43.5
6050012150 S.XTL CR-806 [Others] B 87/43.5
X2001 6050011550 S.XTL CR-747 B 106.5/27
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[DISPLAY UNIT]
[REPLACEMENT UNITS]
ORDER NO. UNIT NAME
0324270102
0324270105
U 7000 #02 FRONT
U 7000 #05 FRONT
[EUR], [FRA], [ESP], [EXP], [UK]
[USA]
