Icom IC-7000 Service Manual

SECTION 6 MECHANICAL PARTS AND DISASSEMBLY
6 - 1
[MAIN UNIT]
MP1 8510017200 2427 A-shield plate 1
MP2 8930067510 2427 B-earth spring 1
MP3 8930030380 Ferrite sheet (C) 15 × 8 × 2 1
MP4 8930068000 Shield sponge (AT) 1
MP101 8510017330 2427 LPF case Y807 1
MP102* 8930068000 Shield sponge (AT) 1
MP201 8510017210 2427 B-shield plate 1
MP501* 8510017620 2427 mix shield plate 1
MP802 8930067500 2427 A-earth spring 1
MP1951 8510017200 2427 A-shield plate 1
MP2001 8510017170 2427 mic plate 1
MP2002 8930068240 2427 C-earth spring 1
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
[FRONT UNIT]
W1 8900013940 Cable OPC-1447 (N=10, L=30) 1
W2 8900013990 Cable OPC-1445 1
DS1 5030002820 LCD LTA025A161A 1
EP1 0880001670 Encoder EX-2832 1
MP1 8210021760 2427 front panel 1
MP2 8210021770 2427 rear panel 1
MP4 8310063800 2427 window plate 1
MP5 8930069540 2427 A-window sheet 1
MP11 8610012370 Knob N328 1
MP12 8610012380 Knob N328 (A) 1
MP13 8610012390 Knob N329 1
MP14 8610012400 Knob N330 1
MP18 8930065660 2427 brake button 1
MP19 8930065541 2427 power button-1 1
MP20 8930065550 2427 release button 1
MP21 8610012340 Knob K246 1
MP22 8610012330 Knob K247 1
MP23 8610012320 Knob K248 1
MP24 8610012311 Knob K249-1 1
MP25 8610012300 Knob K250 1
MP26 8610012290 Knob K251 1
MP27 8610012280 Knob K252 1
MP28 8610012270 Knob K253 1
MP29 8610012260 Knob K254 1
MP30 8610012250 Knob K255 1
MP31 8610012240 Knob K255 (A) 1
MP32 8610012210 Knob K256 1
MP33 8610012220 Knob K257 1
MP34 8610012230 Knob K258 1
MP35 8930065530 2427 TS lock button 1
MP41 8930065590 2427 LCD holder 1
MP42 8210021790 2427 reflector 1
MP43 8850002610 Plain washer (AI) 1
MP44 8830002440 2427 nut 1
MP51 8930065570 2427 A-release button 1
MP52 8930065580 2427 B-release button 1
MP61 8950006480 2427 B-contact base 1
MP64 8930065610 2427 LCD filter 1
MP65 8930069670 2427 A-LCD sheet 1
MP67 8930065600 Coil spring (AI) 2
MP72 8830001010 Hex nut (A) 2
MP74 8930036740 1691 brake pad 2
MP81 8810009220 Screw PH B0 M2 × 8 ZK (BT) 3
MP82 8810009220 Screw PH B0 M2 × 8 ZK (BT) 2
MP83 8930066680 Coil spring (AJ) 2
MP84 8850000110 Flat washer M2 NI BS 2
MP85 8810008640 Screw FH BT M2 × 4 NI-ZU 2
MP86 8930065560 2427 slide button 1
MP87 8010020110 2427 LCD frame 1
MP88 8930066450 2427 A-prism sheet 1
MP89 8930066440 2427 B-prism sheet 1
MP90 8930062190 Double side tape (AJ) 2
MP91 8610012551 Knob N331 assembly -1 1
(incl: Base, Cover, Finger reset, etc)
MP101 8930066760 2427 A-sponge 2
MP102 8930066750 2427 B-sponge 1
MP103 8930066740 2427 C-sponge 1
MP104 8930066730 2427 D-sponge 1
MP106 8930067580 Insulation sheet (LG) 1
MP107 8930049260 Himelon sheet CA 2
MP108 8930067710 2427 A-sheet 1
MP109 8930067720 2427 B-sheet 1
MP110 8930067700 2427 B.P. sheet 1
MP111 8930067960 Sponge (IQ) 1
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
[DISPLAY UNIT]
MP1 8510016980 2427 shield case 1
MP2 8510016970 2427 shield plate 1
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
[VR UNIT]
R1 7210003230 Variable resistor TP96D00A-17F-10KBX2 1
S1 2250000170 Encoder TP90D96AE20-17F (1352) 1
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
[LOGIC UNIT]
BT1301 3020000330 Lithium battery ML920S/F9D 1
MP1 8510017000 2427 logic case 1
MP2 8510016990 2427 logic cover 1
MP3 8930068080 Thermally sheet (AU) 1
MP5 8930068370 2427 A-magnetic shield 1
MP6 8930056010 Enboss tape (K) 2
MP7 8930068370 2427 A-magnetic shield 1
MP201 8930055051 Thermally sheet (V)-1 1
MP301 8930062210 Thermally sheet (AL) 1
MP1301 8930052770 Double coated tape (Y) 1
MP2221 8930055051 Thermally sheet (V)-1 1
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
[DDS UNIT]
J1051 6450001790 Connector HLJ7000-01-3010 1
J1101 6450001640 Connector TCS5044-01-4111 1
J1151 6450001840 Connector TCS7568-43-201 1
MP201 8510017200 2427 A-shield plate 1
MP202* 8510017440 2427 B-DDS plate 1
MP301* 8510017230 2427 DDS case 1
MP302 8930024170 Earth spring (G) 1
MP321* 8510017250 2427 DDS plate 1
MP451 8510017500 2427 C-shield plate 1
MP452* 8510017240 2427 A-DDS case 1
MP453* 8930063970 Shield sponge (AM) 1
MP601 8930067520 2427 DDS spring 1
MP801* 8930024170 Earth spring (G) 1
MP851 8510017260 2427 A-DDS plate 1
MP1101 8930067530 Sponge (IP) 1
MP1102 8930067520 2427 DDS springe 1
ORDER
NO.
REF.
NO.
DESCRIPTION QTY.
*: Refer to SEC 8 BOARD LAYOUTS.
