5 - 14
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[PA UNIT]
R417 7030000140 S.RES MCR10EZHJ 10
Ω
B 95.5/132.5
R418 7030000010 S.RES MCR10EZHJ JPW B 99.3/133.9
R451 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
) B 81.5/121.7
R452 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7
Ω
) B 85.5/119.3
R453 7030003260 S.RES ERJ3GEYJ 330 V (33
Ω
) B 81.6/118.4
R454 7030003860 S.RES ERJ3GE JPW V B 77.3/116
R455 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 73.2/117.5
R456 7030003700 S.RES ERJ3GEYJ 154 V (150 k
Ω
) B 72/114.4
R457 7030003750 S.RES ERJ3GEYJ 394 V (390 k
Ω
) B 71.2/111.9
R458 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) B 73.8/112.4
R459 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 69.6/111.3
R460 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) B 76.6/112.1
R461 7030003270 S.RES ERJ3GEYJ 390 V (39
Ω
) B 77.7/103.3
R462 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 72.9/99.6
R463 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 74.4/102.4
R464 7030003210 S.RES ERJ3GEYJ 120 V (12
Ω
) B 74.2/105.7
R465 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 66.5/101.7
R466 7030003860 S.RES ERJ3GE JPW V B 62.1/100.2
R467 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 75/118.9
R468 7030008240 S.RES ERJ12YJ0R00U B 89.1/121.9
R470 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) B 67.7/98.8
R471 7030003270 S.RES ERJ3GEYJ 390 V (39
Ω
) B 69.6/98.3
R472 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 69.6/99.5
R473 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 69.6/100.7
R474 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 63.5/96.9
R475 7030003340 S.RES ERJ3GEYJ 151 V (150
Ω
) B 64.9/96.7
R476 7030003270 S.RES ERJ3GEYJ 390 V (39
Ω
) B 64.8/94.9
R477 7030003360 S.RES ERJ3GEYJ 221 V (220
Ω
) B 61.8/97.6
R502 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 112.1/87.9
R503 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 112.6/86
R504 7030000260 S.RES MCR10EZHJ 100
Ω
T 114.2/86.2
R505 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) B 119.9/124.8
R507 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 110.2/123.1
R508 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 107.1/121.9
R510 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 110.3/125.7
R511 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) B 112.1/133.9
R512 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 107.1/123.1
R513 7030010520 S.RES ERJ1TYJ 101U (100
Ω
) B 103.7/114.2
R515 7030006060 S.RES ERJ12YJ100U (10
Ω
) T 92.1/108.9
R516 7030003860 S.RES ERJ3GE JPW V T 90.6/114.3
R517 7030010520 S.RES ERJ1TYJ 101U (100
Ω
) B 103.7/118.4
R518 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 97.5/112.7
R519 7030000010 S.RES MCR10EZHJ JPW B 111.1/119.5
R551 7030003470 S.RES ERJ3GEYJ 182 V (1.8 k
Ω
) T 78.2/117.8
R552 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7
Ω
) T 76.7/119.1
R553 7030003260 S.RES ERJ3GEYJ 330 V (33
Ω
) T 73/118.9
R554 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 66.8/120.4
R555 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) T 68.1/114.7
R556 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 69.9/116.6
R557 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) T 65.7/112.9
R558 7030003710 S.RES ERJ3GEYJ 184 V (180 k
Ω
) T 70.5/111.2
R559 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 65.7/111.7
R560 7030003720 S.RES ERJ3GEYJ 224 V (220 k
Ω
) T 65.6/110.5
R561 7030003740 S.RES ERJ3GEYJ 334 V (330 k
Ω
) T 68.3/112.4
R562 7030003270 S.RES ERJ3GEYJ 390 V (39
Ω
) T 70.1/106.6
R563 7030003420 S.RES ERJ3GEYJ 681 V (680
Ω
) T 65.4/107.3
R564 7030003210 S.RES ERJ3GEYJ 120 V (12
Ω
) T 63.5/103
R565 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 65.8/108.1
R567 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 70.1/104
R568 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) T 69.7/100.7
R570 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) T 62.8/100.3
R575 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 68.4/100.7
R576 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) T 71.8/100
R577 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) T 68/120.4
R578 7030003540 S.RES ERJ3GEYJ 682 V (6.8 k
Ω
) T 69.9/119
R701 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 82.2/16.9
R702 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 83/14.5
R703 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 80.6/16.9
R704 7030003500 S.RES ERJ3GEYJ 332 V (3.3 k
Ω
) B 79.7/14.5
R705 7030009300 S.RES ERJ1WY0R00U B 134.6/23.8
R721 7030011240 S.RES LRF3W-LF-01-R020F B 83/22.3
R722 7030011240 S.RES LRF3W-LF-01-R020F B 83/29.6
R723 7030004040 S.RES ERJ3GEYJ 4R7 V (4.7
Ω
) B 140.5/14.7
R733 7030009591 S.RES ERA3YED 472V (4.7 k
Ω
) B 138.6/10.4
R734 7510001470 S.TMR NTCG20 4AG 473JT T 111.9/58.2
R735 7030009591 S.RES ERA3YED 472V (4.7 k
Ω
) B 140.2/12.5
R736 7510001470 S.TMR NTCG20 4AG 473JT T 153.3/77.1
R742 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 86.4/6.5
R743 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 82.5/10.5
R744 7030003860 S.RES ERJ3GE JPW V T 67.8/9.6
R749 7030003860 S.RES ERJ3GE JPW V B 65/5.2
R750 7030003860 S.RES ERJ3GE JPW V B 66.6/5.2
R773 7030003860 S.RES ERJ3GE JPW V T 103.4/9.5
R960 7030003860 S.RES ERJ3GE JPW V B 43.2/125.7
R961 7030003380 S.RES ERJ3GEYJ 331 V (330
Ω
) B 42/138.3
R962 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 37.4/137.8
R963 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 40.3/126.3
R964 7030003860 S.RES ERJ3GE JPW V B 24.8/131.2
R965 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 32.6/130.5
R966 7030008190 S.RES ERJ12YJ330U (33
Ω
) B 11.1/129.6
R967 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 34.2/130.5
R968 7030003860 S.RES ERJ3GE JPW V B 24.8/132.8
R969 7030003600 S.RES ERJ3GEYJ 223 V (22 k
Ω
) B 32.6/133.6
R970 7030003680 S.RES ERJ3GEYJ 104 V (100 k
Ω
) B 34.2/133.6
R971 7540000130 ABS 2P-50A-301
R972 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 17.4/140.1
R973 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 18.9/138.5
R974 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 19.4/136.6
R994 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 22.4/2.6
R995 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 22.4/6.8
R996 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 21.6/5.4
R997 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 21.6/8.2
R998 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 54.1/4.4
R999 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 54.5/3.1
R1000 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 51.2/3.5
R1001 7030003320 S.RES ERJ3GEYJ 101 V (100
Ω
) T 49.3/4.9
R1002 7030000280 S.RES MCR10EZHJ 150
Ω
T 48/9.7
R1003 7030000290 S.RES MCR10EZHJ 180
Ω
T 47.5/7.9
C101 4030011600 S.CER C1608 JB 1E 104K-T T 151.9/25.1
C102 4030011600 S.CER C1608 JB 1E 104K-T B 150.8/29.3
C103 4030011340 S.CER C1608 CH 1H 471J-T T 152.7/27.2
C104 4030011600 S.CER C1608 JB 1E 104K-T T 147.8/32.2
C105 4510004591 ELE 16 ME 470 HC
C106 4030011600 S.CER C1608 JB 1E 104K-T B 142.7/29.2
C107 4030011600 S.CER C1608 JB 1E 104K-T T 151.6/39.7
C108 4030011600 S.CER C1608 JB 1E 104K-T T 149.2/36.5
C109 4030007130 S.CER C1608 CH 1H 101J-T B 146.6/42.1
C112 4030011600 S.CER C1608 JB 1E 104K-T B 139.2/35.1
C113 4030011600 S.CER C1608 JB 1E 104K-T T 144.6/44.4
C114 4030011600 S.CER C1608 JB 1E 104K-T B 134.1/37
C116 4030007060 S.CER C1608 CH 1H 270J-T T 144.6/45.8
C118 4030007130 S.CER C1608 CH 1H 101J-T T 143.5/48.5
C119 4030007130 S.CER C1608 CH 1H 101J-T T 144/50.4
C120 4030007020 S.CER C1608 CH 1H 120J-T T 143.5/47.2
C122 4510008500 S.ELE EEE1CA101WP T 121.5/11.2
C151 4030011600 S.CER C1608 JB 1E 104K-T T 59.2/54.8
C152 4030006880 S.CER C1608 JB 1H 472K-T B 61.6/36.2
C153 4030011600 S.CER C1608 JB 1E 104K-T B 63.1/56
C154 4030006860 S.CER C1608 JB 1H 102K-T B 63.1/54.7
C201 4030006860 S.CER C1608 JB 1H 102K-T T 145.6/53
C202 4030006860 S.CER C1608 JB 1H 102K-T T 143/53
C204 4030011600 S.CER C1608 JB 1E 104K-T B 139.3/48.4
C205 4030006860 S.CER C1608 JB 1H 102K-T B 123.3/48.6
C206 4030017810 S.CER C1608 CH 1H 102J-T B 133.5/50.6
C207 4030017810 S.CER C1608 CH 1H 102J-T B 139.3/49.7
C208 4030011600 S.CER C1608 JB 1E 104K-T B 132/50.6
C209 4030007170 S.CER C1608 CH 1H 221J-T B 139.3/51
C214 4030018940 S.CER GRM31A7U2J331JW31D T 116.3/76.1
C215 4030018930 S.CER GRM31A7U2J221JW31D T 122.2/73.9
C217 4030011600 S.CER C1608 JB 1E 104K-T T 144.3/53
C218 4030018930 S.CER GRM31A7U2J221JW31D T 101/88.5
C219 4030018930 S.CER GRM31A7U2J221JW31D B 82.4/99.7
C251 4030011180 S.CER GRM31M2C2H220JV01L B 134.9/66
C252 4030011180 S.CER GRM31M2C2H220JV01L B 142.2/70.6
C253 4030011080 S.CER GRM31M2C2H6R0DV01L B 145.5/79
C254 4030011160 S.CER GRM31M2C2H150JV01L B 127.7/65.3
C261 4030012480 S.CER GRM31M2C2H121JV01L B 131.7/75.1
C262 4030018940 S.CER GRM31A7U2J331JW31D B 126/80.1
C263 4030018770 S.CER C3216 CH 2J 102J-T B 122.1/80.7
C266 4030018950 S.CER GRM31A7U2J681JW31D B 119.7/80.2
C267 4030018930 S.CER GRM31A7U2J221JW31D B 124/85.3
C301 4030001100 S.CER GRM216B11H102KA01D B 91.7/100.6
C302 4030001020 S.CER GRM2162C1H121JA01D B 93.8/100.6
C303 4030011600 S.CER C1608 JB 1E 104K-T B 110.8/85.5
C304 4030017320 S.CER GRM21BB11H104KA11L B 94.8/97.6
C305 4510004591 ELE 16 ME 470 HC
C306 4030006860 S.CER C1608 JB 1H 102K-T B 80/39.6
C307 4030006860 S.CER C1608 JB 1H 102K-T B 98/39.5
C308 4030006860 S.CER C1608 JB 1H 102K-T B 88/11.2
C309 4030011600 S.CER C1608 JB 1E 104K-T T 105.8/78.3
C311 4030018750 S.CER C3225 CH 2J 682K-T B 92.7/78.5
C312 4030018750 S.CER C3225 CH 2J 682K-T B 84.9/78.5
C313 4030011600 S.CER C1608 JB 1E 104K-T T 76.8/87.8
C314 4030018750 S.CER C3225 CH 2J 682K-T B 96.9/77.6
C315 4030018750 S.CER C3225 CH 2J 682K-T B 80.6/77.6
C319 4030011730 S.CER GRM31M2C2H101JV01L B 110/48.8
C320 4030011730 S.CER GRM31M2C2H101JV01L B 71.1/48.9
C323 4030003810 S.MIC UC342H 1200J-T B 91.4/46.4
C324 4320001050 S.MIC UC342H 3900J-T T 94.4/40.2
C325 4320001070 S.MIC UC342H 3300J-T B 94.4/40.7
C327 4030011790 S.CER GRM55RF52A684ZD01L T 65.9/46.3
C331 4030011600 S.CER C1608 JB 1E 104K-T T 108.3/78.3
C332 4030011600 S.CER C1608 JB 1E 104K-T B 69.5/81.4
C333 4030018940 S.CER GRM31A7U2J331JW31D B 88.4/101.8
C340 4030006860 S.CER C1608 JB 1H 102K-T B 80.2/107.1
C341 4030006860 S.CER C1608 JB 1H 102K-T B 90.2/107.1
C342 4030006860 S.CER C1608 JB 1H 102K-T B 85.2/91.9
C404 4030006860 S.CER C1608 JB 1H 102K-T B 151.7/71.4
C405 4030011740 S.CER GRM32N2C2H201JV01L T 145.3/105.7
C406 4030006860 S.CER C1608 JB 1H 102K-T B 132.4/129.7
S.=Surface mount
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
[PA UNIT]
