Icom IC-7000 Service Manual

5 - 25
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[HM-151]
IC1 1140011490 S.IC µPD789071MC-041-5A4-E1 B 51.1/24.5
IC3 1110006310 S.IC BD5245G-TR B 67.3/34.8
Q1 1530001941 S.TR 2SC2712-BL (TE85R,F) B 26.1/11
Q2 1590000680 S.TR DTC114EUA T106 B 21.6/34.8
Q3 1590001330 S.TR DTA114EUA T106 B 24.7/34.8
Q5 1510000771 S.TR 2SA1586-GR (TE85R,F) B 54.8/37.7
D1 1790000950 S.ZEN MA8056-M (TX) B 23.1/17
D3 1750000940 S.DIO ISS400 TE61 B 64.7/23.2
D4 1750000940 S.DIO ISS400 TE61 B 64.7/29.2
D6 1750000940 S.DIO ISS400 TE61 B 58.7/20.8
D7 1750000940 S.DIO ISS400 TE61 B 42.8/16.7
D9 1750000940 S.DIO ISS400 TE61 B 34.1/16.3
D10 1750000940 S.DIO ISS400 TE61 B 34.9/17.8
D11 1750000940 S.DIO ISS400 TE61 B 38.8/14.5
D16 1730002280 S.ZEN MA8091-M (TX) B 55.2/14.5
D17 1730002280 S.ZEN MA8091-M (TX) B 48.8/14.5
D18 1730002280 S.ZEN MA8091-M (TX) B 13.1/13.7
X1 6060000610 S.CER EFOS4914E3 B 42.6/22.3
L1 6200005051 S.COL NLV25T-330J B 12.3/28.9
L2 6200005011 S.COL NLV25T-100J B 11/13.9
R2 7030000400 S.RES MCR10EZHJ 1.5 k
Ω
B 24.2/8.3
R3 7030000400 S.RES MCR10EZHJ 1.5 k
Ω
B 41.9/8.3
R4 7030000400 S.RES MCR10EZHJ 1.5 k
Ω
B 57.3/8.2
R5 7030003400 S.RES ERJ3GEYJ 471 V (470
Ω
) B 28.6/11.2
R6 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 26.8/34.7
R7 7030003620 S.RES ERJ3GEYJ 333 V (33 k
Ω
) B 23.3/36.8
R8 7030003550 S.RES ERJ3GEYJ 822 V (8.2 k
Ω
) B 19.1/33.7
R11 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 53/35
R12 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 55/34.2
R14 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 47.2/6.1
R18 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 41.6/33.6
R19 7030003640 S.RES ERJ3GEYJ 473 V (47 k
Ω
) B 38.4/34.5
R22 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 37.9/18.7
R23 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 56.1/18.1
R24 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 58/18.6
R25 7030003520 S.RES ERJ3GEYJ 472 V (4.7 k
Ω
) B 59.8/18.9
R27 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 68.1/32.5
R35 7030000400 S.RES MCR10EZHJ 1.5 k
Ω
B 69.1/11.9
R36 7030003560 S.RES ERJ3GEYJ 103 V (10 k
Ω
) B 20.5/30.6
R37 7030003460 S.RES ERJ3GEYJ 152 V (1.5 k
Ω
) B 19.1/30.6
R39 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 24.4/5.7
R40 7030003480 S.RES ERJ3GEYJ 222 V (2.2 k
Ω
) B 24.4/3
R41 7030003580 S.RES ERJ3GEYJ 153 V (15 k
Ω
) B 17/32.7
R42 7030003860 S.RES ERJ3GE JPW V B 68.4/21.6
R44 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 57.3/22.1
R45 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 53.9/18
R46 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 37.8/15.8
R47 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 37.6/17.1
R48 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 45.3/17.6
R49 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 57.3/26.2
R50 7030003440 S.RES ERJ3GEYJ 102 V (1 k
Ω
) B 58.1/23.4
C1 4030006850 S.CER C1608 JB 1H 471K-T B 52/16.9
C2 4510008500 S.ELE EEE1CA101WP B 35.5/5.8
C5 4030007050 S.CER C1608 CH 1H 220J-T B 14.9/30.4
C9 4030007050 S.CER C1608 CH 1H 220J-T B 20.8/16.8
C10 4030007050 S.CER C1608 CH 1H 220J-T B 19.8/11.6
C11 4030007050 S.CER C1608 CH 1H 220J-T B 17/5.6
C12 4030011600 S.CER C1608 JB 1E 104K-T B 64.9/34.4
C13 4030011600 S.CER C1608 JB 1E 104K-T B 44.3/27.6
C14 4030006900 S.CER C1608 JB 1H 103K-T B 67.5/37.2
C16 4030006860 S.CER C1608 JB 1H 102K-T B 14.7/13.6
C17 4030006880 S.CER C1608 JB 1H 472K-T B 11.7/17.4
C18 4030006880 S.CER C1608 JB 1H 472K-T B 10.4/17.4
C19 4030011600 S.CER C1608 JB 1E 104K-T B 13/25.8
C21 4030011600 S.CER C1608 JB 1E 104K-T B 11.7/25.8
C22 4030011600 S.CER C1608 JB 1E 104K-T B 10.4/28.5
C23 4030011600 S.CER C1608 JB 1E 104K-T B 23.1/14
C24 4030011600 S.CER C1608 JB 1E 104K-T B 67.2/12.1
C25 4030011600 S.CER C1608 JB 1E 104K-T B 25.6/32.2
C26 4030011600 S.CER C1608 JB 1E 104K-T B 44.5/6.1
C27 4030011600 S.CER C1608 JB 1E 104K-T B 51.7/35
C29 4510008540 S.ELE EEE1CA100SR B 26.4/16
C30 4030010210 S.CER C3216 JB 1C 105M-T B 19.8/4.6
C31 4510008540 S.ELE EEE1CA100SR B 28.3/4.9
C32 4030011600 S.CER C1608 JB 1E 104K-T B 55/35.7
J1 6510023110 CNR 3008L-8P8C
DS1 5010000120 S.LED LN1371G-(TR) T 21.9/11
DS2 5010000120 S.LED LN1371G-(TR) T 21.9/32
DS3 5010000120 S.LED LN1371G-(TR) T 39.3/11
DS4 5010000120 S.LED LN1371G-(TR) T 39.3/32
DS5 5010000120 S.LED LN1371G-(TR) T 55.9/2.5
DS6 5010000120 S.LED LN1371G-(TR) T 56.2/26.8
DS7 5010000120 S.LED LN1371G-(TR) T 71.7/14.8
DS8 5010000120 S.LED LN1371G-(TR) T 72.2/33.8
DS10 5040002890 S.LED SML-310FT T86 T 51.6/5
DS11 5040002620 S.LED SML-311UT T86 T 51.6/38
MC1 7700002310 MIC EM-140
S1 2260000980 SW SKHHLP014A
W1 8900011270 WIR OPC-1153
EP1 6910012350 S.BEA MMZ1608Y 102BT B 10.4/25.8
EP2 6910012350 S.BEA MMZ1608Y 102BT B 14.3/17.4
EP3 6910012350 S.BEA MMZ1608Y 102BT B 13/17.4
EP4 6910012350 S.BEA MMZ1608Y 102BT B 14.7/11
EP5 6910012350 S.BEA MMZ1608Y 102BT B 15/25
S.=Surface mount
REF ORDER
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[HM-151]
