Icom IC-7100 Basic Manual

5-1
Section 5
D-STAR OPERATION <BASIC>
D-STAR Operating procedures .............................................5-2
Making a Local area call
D
........................................................5-2
Making a Gateway call
D
..........................................................5-3
About “UR?” and “RPT?” error messages ..........................5-5
Shows
D
“UR?” .........................................................................5-5
Shows
D
“RPT?”or“RX” ...........................................................5-5
Shows
D
“L” ...............................................................................5-5
Capturing a call sign .............................................................5-6
“FROM” (Access repeater) setting .......................................5-7
U
D
sing the preloaded repeater list ..........................................5-8
U
D
sing the DR mode scan ......................................................5-9
Using the Repeater Search function
D
.....................................5-10
U
D
sing the TX History .............................................................5-12
“TO” (Destination) setting .....................................................5-13
Usingthe“LocalCQ”(LocalAreacall)
D
..................................5-14
Using the
D
“GatewayCQ” (Gateway call) ................................5-15
U
D
sing the “Your Call Sign” .....................................................5-16
U
D
sing the RX History .............................................................5-17
U
D
sing the TX History .............................................................5-18
D
D
irectly inputting (UR) ...........................................................5-19
D
D
irectly inputting (RPT) .........................................................5-20
IMPORTANT!
•Therepeaterlistdescribedinthismanualmaydifferfromyourtrans-
ceiver’s preloaded contents.
•Although Japanese repeaters are used in the setting examples, the
Japanese repeater node (port) letters are different from those in other
countries.
Be sure to add a repeater node letter as the 8th digit in the call sign
field after a repeater call sign according to the repeater frequency band
shown below.
1200 MHz: A (B in Japan)
430 MHz: B (A in Japan)
144 MHz: C (no D-STAR repeaters in Japan)
‘FM’ means ‘Full Manual.’
‘sec. MM’ means section number.
So when ‘(FM sec. MM)’ is described on this manual, see the PDF type
Full Manual’s section number for your reference.
Section 1 PANEL DESCRIPTION
Section 2 INSTALLATION AND CONNECTIONS
Section 3 BASIC OPERATION
Section 4 D-STAR INTRODUCTION
Section 5 D-STAR OPERATION <BASIC>
Section 6 SET MODE
Section 7 CE

Icom IC-7100 Specifications

General

Supply	13.8 V DC ±15%
Voltage	13.8 V DC
Operating Temperature	-10°C to +60°C
Frequency Coverage	0.030-199.999 MHz, 400-470 MHz
Modes	SSB, CW, AM, FM, DV
Output Power	HF/50MHz: 100W, 144MHz: 50W, 430MHz: 35W
Receiver Type	Superheterodyne
Antenna Connector	SO-239 (HF/50MHz/144MHz), N-type (430MHz)
Weight	Main unit: 2.3 kg
Type	Base/Mobile
Frequency Range TX	1.8–54 MHz, 144–148 MHz, 430–450 MHz
Frequency Range RX	0.030–199.999 MHz, 400–470 MHz
Memories	505
Current Consumption	TX: 22 A, RX: 1.2 A
