Icom IC-7300 - Page 40

5-19
REF PARTS
DESCRIPTION M.
H/V
NO. NO.
LOCATION
[SD UNIT]
R1 7030003360 S.RES ERJ3GEYJ 221 V (220) T 35.1/11.5
R2 7030003250 S.RES ERJ3GEYJ 270 V (27) T 35.1/13.9
R3 7030003250 S.RES ERJ3GEYJ 270 V (27) T 35.1/15.1
R4 7030003250 S.RES ERJ3GEYJ 270 V (27) T 35.1/18.7
R5 7030003250 S.RES ERJ3GEYJ 270 V (27) T 35.1/19.9
R6 7030003250 S.RES ERJ3GEYJ 270 V (27) T 35.1/17.5
R8 7030003250 S.RES ERJ3GEYJ 270 V (27) T 35.1/12.7
R9 7030003360 S.RES ERJ3GEYJ 221 V (220) T 35.1/10.3
C1 4030011600 S.CER C1608 JB 1E 104K-T ATEX T 32.6/16.0
C2 4030019560 S.CER GRM21BB31C106KE15L T 31.1/15.6
J1 6510028980 S.CON SCDABA0500 T 13.9/15.3
J2 6510031540 S.CON 12FHJ-SM1-TB(LF)(SN) T 40.3/15.3
EP7 6910019900 S.BEA MPZ1608S601AT1 T 35.1/16.3
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
Eqv.= This component is equivalent to the REF No. component listed above, and
may be substituted on parts orders and repairs.
