Icom IC-7300 - Section 6 Mechanical Parts

6-1
[MAIN PARTS]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J21* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J45* 6510018961 B2B-PH-SM4-TB (LF) (SN) 1
J51* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J71* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J101* 6510024522 12FLT-SM2-TB (LF) (SN) (M) 1
J491* 6510025142 10FLT-SM2-TB (LF) (SN) (M) 1
J601 6510026540 UBB-4R-D14T-4D (LF) (SN) 1
J691 6510025940 PJ-3047S <XIN> 1
J751 6510025940 PJ-3047S <XIN> 1
J752* 6510014961 B2B-ZR-SM4-TF (LF) (SN) 1
J761* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J771 6450001641 TCS5044-0141177 1
J901* 6510025142 10FLT-SM2-TB (LF) (SN) (M) 1
J1231 6510028210 SJ050010 (TMP-J01X-V6) 1
S371* 2230001480 LS37J2-T 1
BT381* 3020000390 ML414HIV01E 1
EP1202* 6910002161 CASE-BM7H-LF 1
EP1262* 6910002161 CASE-BM7H-LF 1
EP1300* 6910026020 CMBA0210101402-00 <MSK> 1
EP1333* 6910002161 CASE-BM7H-LF 1
MP201* 8510020100 3182 DC-DC CASE Y1220 1
MP721* 8510021840 3765 MAIN SHIELD CASE Y1377 1
MP1231* 8930067510 2427 B-EARTH SPRING 1
MP1262 8930094410 3765 BM SPRING 1
MP1263 8930082601 SHIELD SPONGE (CT)-1 1
[RF UNIT]
[PA UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J101 6450002520 RL-1515-2 (B.B)-L <KUO> 1
J201 6510023740 LGR4609-7000 1
J1001 6510028210 SJ050010 (TMP-J01X-V6) 1
J1071 6510028210 SJ050010 (TMP-J01X-V6) 1
J1311* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J1431 6510028210 SJ050010 (TMP-J01X-V6) 1
MP1251* 8510021820 3765 RF-SHIELD CASE Y1375 1
REF ORDER
DESCRIPTION QTY.
NO. NO.
J101* 6510028210 SJ050010 (TMP-J01X-V6) 1
J301* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
J331* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J801* 6510028210 SJ050010 (TMP-J01X-V6) 1
J961* 6510028210 SJ050010 (TMP-J01X-V6) 1
F2* 5210000940 1205 1
F201* 5220000400 FHA010-01F 1
W1 8900017860 OPC-1857 [#02] 1
8900018220 OPC-1943 [#03] 1
8900018220 OPC-1943 [#05] 1
8900018220 OPC-1943 [#06] 1
8900017860 OPC-1857 [#07] 1
8900017860 OPC-1857 [#08] 1
8900017860 OPC-1857 [#12] 1
MP301* 8930075440 3015 RUG SPRING Y1115 1
MP302* 8930075440 3015 RUG SPRING Y1115 1
SECTION 6 MECHANICAL PARTS
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
[CHASSIS PARTS]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J1 6510028411 MR-DS-01-2 <GA> 1
SP1 2510002000 057D0805 1
MF1 2710001060 FD128025HB-N (2N7R1) <USE> 1
W1** 8970024631 1.5DCOAXIAL170MM-1 C31/C31 1
W3** 8970024412 1.5DCOAXIAL330MM-2 (T) C31/C31 1
W5** 8970024252 1.5DCOAXIAL240MM-2 C31/C31 1
W7** 8900016990 OPC-1741 (1.5DCOAXIAL110MM) 1
W11** 8600037600 SX3765 P11*P12CH (3765-1) 1
W15 8920001580 CAB-1186 [#02] 1
8920001670 CAB-1205 [#03] 1
8920001670 CAB-1205 [#05] 1
8920001670 CAB-1205 [#06] 1
8920001580 CAB-1186 [#07] 1
8920001580 CAB-1186 [#08] 1
8920001580 CAB-1186 [#12] 1
W16 8600037380 SX3183 J1101*P1102CH 1
W21** 8910000500 FFC-1055 (P0.5N30L150) 1
W22** 8910000220 FFC-1024 (P0.5N40L120) 1
W23** 8910000530 FFC-1057 (P0.5N30L65 S) 1
W24** 8910000520 FFC-1056 (P0.5N40L100 S) TJM 1
W25** 8900018810 OPC-1974 (P0.5N12L50) 1
EP2 6910025930 S80-5 <USE> 1
MP1 8010023570 3765 CHASSIS 1
MP2 8110010940 3765 U-COVER Y2203 1
MP3 8110010950 3765 L-COVER Y2202 1
MP4 8930093300 3765 SP RUBBER (TOP) 1
MP5 8930093310 3765 NET 1
MP6 8930075100 3015 STAND HOLDER 2
MP7 8930074520 3015 STAND 1
MP9 8930002900 RUBBER LEG (A) SK1912A 2
MP21 8820000530 FLANGE BOLT M4 X 8 NI 1
MP22 8850000140 FLAT WASHER M 4 NI BS 2
MP23 8850000430 S-WASHER M 4 NI 1
MP24 8810008661 PHBT M3 X 8 NI-ZC3 7
MP25 8810008661 PHBT M3 X 8 NI-ZC3 7
MP26 8810008661 PHBT M3 X 8 NI-ZC3 8
MP27 8810008661 PHBT M3 X 8 NI-ZC3 7
MP28* 8810007231 SET SCREWH M3 X 8 ZC3 1
MP29* 8810007231 SET SCREWH M3 X 8 ZC3 4
MP30 8810009461 FLAT M3 X 8 ZK3 14
MP31 8810009461 FLAT M3 X 8 ZK3 10
MP32 8810005771 BIND M3 X 8 ZK3BLACK 2
MP33 8810005771 BIND M3 X 8 ZK3BLACK 2
MP34 8810008661 PHBT M3 X 8 NI-ZC3 2
MP35 8810008661 PHBT M3 X 8 NI-ZC3 1
MP36 8810010580 SET SCREWA M4 X32 4
MP37 8810009651 FLAT BT M3 X 8 NI-ZC3 4
MP51 8410002951 3765 MAIN HEATSINK-1 Y2205A 1
MP52 8930090910 THERMAL SHEET (CL) TC-200CAS (26X37) 1
MP54 8930091820 SHIELD SPONGE (DH) 1
MP55 8930082231 SHIELD SPONGE (CQ)-1 1
MP56 8930091820 SHIELD SPONGE (DH) 1
MP57 8930091820 SHIELD SPONGE (DH) 1
MP58 8850003650 PLAIN WASHER (BA) 4
MP59 8930094660 SPONGE (OC) 1
MP60 8930037770 THERMAL SHEET AY 2
MP61 8930037770 THERMAL SHEET AY 2
MP62 8930094670 SPONGE (OD) 1
MP63 8930084330 THERMAL SHEET (CA)TC600HS1.4 (6.9X9) 3
MP64 8930094510 SPONGE (NZ) 2
MP65 8930085780 SPONGE (LX) 1
MP66* 8930094670 SPONGE (OD) 1
MP67* 8930094720 RUBBER SHEET (CT) 1
MP68* 8930057311 SHIELD SPONGE (I)-1 [#03] 1
8930057311 SHIELD SPONGE (I)-1 [#05] 1
8930057311 SHIELD SPONGE (I)-1 [#06] 1
MP69* 8930095180 FERRITE SHEET (BB) [#03] 1
8930095180 FERRITE SHEET (BB) [#05] 1
8930095180 FERRITE SHEET (BB) [#06] 1
MP70* 8930095110 SHIELD SPONGE (EH) [#02] 1
8930095110 SHIELD SPONGE (EH) [#03] 1
8930095110 SHIELD SPONGE (EH) [#05] 1
8930095110 SHIELD SPONGE (EH) [#06] 1
