Icom IC-7300 - Page 42

6-2
[TUNER UNIT]
[PBT UNIT]
[VR UNIT]
[RIT UNIT]
[MIC UNIT]
[SD UNIT]
[PHONE UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
REF ORDER
DESCRIPTION QTY.
NO. NO.
W2001* 8970024721 1.5DCOAXIAL140MM-1 C31/C31 1
J1001* 6510028210 SJ050010 (TMP-J01X-V6) 1
J1801* 6510021722 30FLT-SM2-TB (LF) (SN) (M) 1
J2001* 6510028210 SJ050010 (TMP-J01X-V6) 1
J2002* 6510028210 SJ050010 (TMP-J01X-V6) 1
MP1301* 8510013390 2355 MIX CASE 1
MP2001* 8930075430 3015 ANT SPRING Y1091 1
J1* 6510029480 06FH-SM1-TB (LF) (SN) 1
S1 2250000960 TP90D96AE20-30.5F-3765 1
J1* 6510029480 06FH-SM1-TB (LF) (SN) 1
J1* 6510029480 06FH-SM1-TB (LF) (SN) 1
S1 2250001010 TP90N00AE20-14.5F-3765A 1
J1 6510000191 FM214-8SS (P)-1 1
J2* 6510019971 52808-1071 1
J1* 6510028980 SCDABA0500 1
J2* 6510031540 12FHJ-SM1-TB (LF) (SN) 1
W1** 8600036920 EX2500 P01*J01MA 1
J1 6450001630 HSJ1406-01-050 1
[FRONT UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
DS1 5030004050 RFE430H-AZH-DNS-000 <TRIA> 1
W1** 8910000070 FFC-1008 (P0.5N6L50) 1
W2** 8910000070 FFC-1008 (P0.5N6L50) 1
W3** 8910000070 FFC-1008 (P0.5N6L50) 1
W4** 8900018000 OPC-1344A (P1N10L70) 1
EP1 0880001360 EX-2500 SENSOR 1
MP1 8210031701 3765 FRONT PANEL ASSEMBLY-1 (including MP2) 1
MP2 8930093270 3765 B-LENS 1
MP3 8610015840 KNOB K-300 ASSEMBLY (including MP4) 1
MP4 8930093260 3765 A-LENS 1
MP5 8610015710 KNOB K-301 1
MP6 8610015720 KNOB K-302 1
MP7 8610015730 KNOB K-303 1
MP8 8610015740 KNOB K-304 1
MP11 8010023630 3765 SUB CHASSIS Y2204 1
MP21 8810008661 PHBT M3 X 8 NI-ZC3 5
MP22 8810008661 PHBT M3 X 8 NI-ZC3 12
MP23 8810008661 PHBT M3 X 8 NI-ZC3 2
MP24 8810008631 PHBT M3 X 6 NI-ZC3 2
MP31 8930093290 3765 BRAKE PLATE 1
MP32 8930093280 3765 BRAKE BUTTON (including MP31) 1
MP33 8930077360 3073 BRAKE PAD 2
MP34 8930094550 3765 BRAKE SHEET 1
MP35 8610015830 KNOB N-432 ASSEMBLY (including MP42) 1
MP36 8610015760 KNOB N-432 COVER (TOP) 1
MP37 8610013880 KNOB N-379 1
MP38 8610011830 KNOB N301 1
MP39 8610013870 KNOB N-378 1
MP40 8610013290 KNOB N-361 1
MP41 8610015780 KNOB N-433 1
MP42 8610010040 KNOB N-239 FINGER REST 1
MP43 8810003560 M4 X 6 SUS 1
MP47 8930057950 DOUBLE SIDE TAPE (AH) 2
MP48 8930094510 SPONGE (NZ) 8
MP49 8930094520 SPONGE (OA) 3
MP50 8930094530 HIMELON SHEET (DM) 1
MP51 8930094530 HIMELON SHEET (DM) 1
MP52 8930094500 3765 VR SHEET 1
MP53 8930094540 DOUBLE SIDE TAPE (CA) 1
MP54 8930083180 SPONGE (LG) 4
MP55 8930032130 THERMAL SHEET AQ 2
MP56 8930094490 3765 KEY SPONGE 1
MP57* 8930037760 INSULATION SHEETDY 1
MP58 8930094650 SPONGE (OB) 1
MP60 8930094680 DOUBLE SIDE TAPE (CC) 1
MP61* 8930088580 HIMELON SHEET (DD) 1
MP62 8930094750 SPONGE (OF) 1
[DISPLAY UNIT]
REF ORDER
DESCRIPTION QTY.
NO. NO.
J51* 6510022692 06FLT-SM2-TB (LF) (SN) (M) 1
J61* 6510022692 06FLT-SM2-TB (LF) (SN) (M) 1
J71* 6510022692 06FLT-SM2-TB (LF) (SN) (M) 1
J101* 6510031070 AYF534035 1
J201* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J301* 6510022692 06FLT-SM2-TB (LF) (SN) (M) 1
J401* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J421* 6510018971 B4B-PH-SM4-TB (LF) (SN) 1
J451* 6510019971 52808-1071 1
J601* 6510022472 40FLT-SM2-TB (LF) (SN) (M) 1
S1* 2230001480 LS37J2-T 1
S2* 2230001480 LS37J2-T 1
S3* 2230001480 LS37J2-T 1
S4* 2230001480 LS37J2-T 1
S5* 2230001480 LS37J2-T 1
S6* 2230001480 LS37J2-T 1
S7* 2230001480 LS37J2-T 1
S8* 2230001480 LS37J2-T 1
S9* 2230001480 LS37J2-T 1
S10* 2230001480 LS37J2-T 1
S11* 2230001480 LS37J2-T 1
S12* 2230001480 LS37J2-T 1
S13* 2230001480 LS37J2-T 1
S14* 2230001480 LS37J2-T 1
S15* 2230001480 LS37J2-T 1
S16* 2230001480 LS37J2-T 1
S17* 2230001480 LS37J2-T 1
S18* 2230001480 LS37J2-T 1
S19* 2230001480 LS37J2-T 1
S20* 2230001480 LS37J2-T 1
S21* 2230001480 LS37J2-T 1
S22* 2230001480 LS37J2-T 1
S23* 2230001480 LS37J2-T 1
S24* 2230001480 LS37J2-T 1
S25* 2230001480 LS37J2-T 1
MP1* 8510002280 VCOSHIELD PLATE (A) FX 15 1
*: Refer to “BOARD LAYOUTS” for the location.
**: Refer to “GENERAL WIRING” for the connection
Screw abbreviations A, B0, BT: Self-tapping PH: Pan head ZK: Black NI-ZU: Nickel-Zinc SUS: Stainless
