Icom IC-7300 - Page 13

– 2 –V1.30
A7292-9EX
■ Additional CI-V commands
(Full manual on the CD)
The following commands are added to the conventional
Command table.
Cmd. Sub Cmd. Data Description
1A* 05 0196
See
below
Send/read SSB-D TX bandwidth
0197 00/01 Inhibit Timer at USB connection
(00=OFF, 01=ON)
* Send/read data
• SSB-D transmission passband width settings
Command : 1A 050196
XX
Higher edge: 0= 2500 Hz
1= 2700 Hz
2= 2800 Hz
3= 2900 Hz
Lower edge: 0= 100 Hz
1= 200 Hz
2= 300 Hz
3= 500 Hz
