7 - 8
M.=Mounted side (T: Mounted on the Top side, B: Mounted on the Bottom side)
S.=Surface mount
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
L204 6200002041 S.COL NLV25T-101J B 11.6/33.1
L250 6200004590 S.COL MLF1608D R18K-T B 8.6/30.3
L251 6200004600 S.COL MLF1608D R15K-T B 8.2/29.1
L252 6200003960 S.COL MLF1608A 1R0K-T B 10.1/24.8
L253 6200004590 S.COL MLF1608D R18K-T B 11.4/22.5
L254 6200004600 S.COL MLF1608D R15K-T B 12.7/23.7
L300 6200011001 S.COL ELJRF 56NJFB T 18.6/39.4
L301 6200011021 S.COL ELJRF 82NJFB T 18.6/37.8
L302 6200010991 S.COL ELJRF 47NJFB T 26.4/36.4
L303 6200007871 S.COL ELJRF 39NJFB T 26.4/35.5
L304 6200007871 S.COL ELJRF 39NJFB T 18.1/36.6
L305 6200006981 S.COL ELJRE R10GFA T 16.7/37.4
L306 6200006981 S.COL ELJRE R10GFA T 7.8/36.7
L307 6200007871 S.COL ELJRF 39NJFB T 8.8/37.7
L308 6200007871 S.COL ELJRF 39NJFB T 4.2/32.8
L309 6200009571 S.COL ELJRE R12GFA T 2.1/32.8
L310 6200011031 S.COL ELJRF R10JFB T 2.6/27.5
L400 6200011031 S.COL ELJRF R10JFB B 21.7/38.4
L401 6200009250 S.COL LQW18ANR22G00D B 17.3/38.1
L402 6200011670 S.COL LQW18AN82NG00D B 14.8/34.2
L403 6200011670 S.COL LQW18AN82NG00D B 17.8/30.3
L404 6200011650 S.COL LQW18AN68NG00D B 15.6/24.6
L405 6200011660 S.COL LQW18ANR15G00D B 21.1/43.1
L450 6200011670 S.COL LQW18AN82NG00D B 24/35.4
L451 6200011670 S.COL LQW18AN82NG00D B 21.9/28.6
L452 6200011650 S.COL LQW18AN68NG00D B 19.5/24.4
L500 6200007961 S.COL ELJRF 6N8JFB (6.8) T 30.1/34.6
L501 6200007921 S.COL ELJRF 15NJFB T 28.2/34.5
L502 6200007941 S.COL ELJRF 10NJFB T 30.1/29.6
L503 6200007941 S.COL ELJRF 10NJFB T 31.3/29.3
L504 6200007961 S.COL ELJRF 6N8JFB (6.8) T 30.4/22.7
L505 6200007931 S.COL ELJRF 12NJFB T 28.8/22.5
L506 6200007881 S.COL ELJRF 33NJFB T 30.2/17.3
L507 6200007921 S.COL ELJRF 15NJFB T 31.7/34.4
L600 6200010850 S.COL LQW18AN22NG00D B 31.8/34.7
L601 6200011650 S.COL LQW18AN68NG00D B 27.2/34.1
L602 6200009280 S.COL LQW18AN27NG00D B 29.4/29.3
L603 6200009220 S.COL LQW18AN15NG00D B 26.8/26
L604 6200009220 S.COL LQW18AN15NG00D B 24.6/20.9
L605 6200009290 S.COL LQW18AN47NG00D B 20.7/16.9
L606 6200010850 S.COL LQW18AN22NG00D B 20/15.1
L607 6200009220 S.COL LQW18AN15NG00D B 17/13.5
L608 6200009280 S.COL LQW18AN27NG00D B 32/36.5
L609 6200009280 S.COL LQW18AN27NG00D B 29.5/31.4
L610 6200005180 S.COL MLF1608D R39K-T B 27.2/36.7
L611 6200011001 S.COL ELJRF 56NJFB B 28.2/37.3
L650 6200009220 S.COL LQW18AN15NG00D B 29.4/25
L651 6200009220 S.COL LQW18AN15NG00D B 28.6/20.5
L652 6200009290 S.COL LQW18AN47NG00D B 31.4/15.9
L653 6200010850 S.COL LQW18AN22NG00D B 33.3/13.8
L654 6200009220 S.COL LQW18AN15NG00D B 29.2/11.5
L700 6200008011 S.COL ELJRF 2N7DFB (2.7) B 2.1/30.8
L701 6200011031 S.COL ELJRF R10JFB B 5.1/25.3
L702 6200008011 S.COL ELJRF 2N7DFB (2.7) B 5.6/21.6
L703 6200008001 S.COL ELJRF 3N3DFB (3.3) B 8.7/17.1
L704 6200007941 S.COL ELJRF 10NJFB B 10.3/12.2
L801 6200003960 S.COL MLF1608A 1R0K-T T 24.3/19.2
L850 6200007941 S.COL ELJRF 10NJFB T 14.3/9.9
L851 6200007981 S.COL ELJRF 4N7DFB (4.7) T 14.3/7.4
L900 6200011031 S.COL ELJRF R10JFB T 21.9/4
L901 6200009351 S.COL ELJRE R22GFA B 16.9/9.7
R1 7030009280 S.RES ERJ2GEJ 391 X (390) B 28.4/45.6
R2 7030009280 S.RES ERJ2GEJ 391 X (390) B 29.3/45.6
R3 7030004980 S.RES ERJ2GEJ 101 X (100) T 31.8/42.2
R4 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 30.9/42.6
R5 7030004980 S.RES ERJ2GEJ 101 X (100) T 26.5/47.5
R6 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
T 28.6/47.9
R7 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 34.3/41.2
R8 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 32.5/38.2
R9 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 19.8/46.9
R10 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 24.2/44.1
R14 7030007270 S.RES ERJ2GEJ 151 X (150) B 23.8/42
R15 7030007270 S.RES ERJ2GEJ 151 X (150) B 31.8/44.7
R100 7030007250 S.RES ERJ2GEJ 220 X (22) T 43.5/30.4
R102 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
T 43.5/31.3
R103 7030004980 S.RES ERJ2GEJ 101 X (100) T 43.1/20.6
R104 7030004980 S.RES ERJ2GEJ 101 X (100) B 48.4/19.9
R105 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 48.2/29.9
R106 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
B 48.6/31.1
R108 7030008010 S.RES ERJ2GEJ 123 X (12 k
)
T 41.7/16.2
R110 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) T 34.5/17.4
R111 7030005530 S.RES ERJ2GEJ 100 X (10) T 36.8/16
R112 7030009320 S.RES ERJ2GEJ 4R7 X (4.7) T 33.6/17.4
R113 7030007270 S.RES ERJ2GEJ 151 X (150) T 45/15.3
R114 7030007270 S.RES ERJ2GEJ 151 X (150) T 45/16.2
R118 7030004980 S.RES ERJ2GEJ 101 X (100) T 31.1/13
R119 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 31.1/12.1
R150 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
T 39.4/34.4
R151 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 37.7/35.9
[RF UNIT]
REF ORDER
DESCRIPTION
M.
H/V
NO. NO.
LOCATION
R153 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 44.5/33.9
R154 7030005160 S.RES ERJ2GEJ 105 X (1 M
)
T 49.1/35.1
R155 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
T 49.1/36.7
R156 7030005230 S.RES ERJ2GEJ 334 X (330 k
)
T 47/37.4
R157 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
T 47/36.5
R158 7030008400 S.RES ERJ2GEJ 182 X (1.8 k
)
B 36.5/37.9
R159 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 35.8/33.8
R160 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 47.7/35.8
R161 7030007330 S.RES ERJ1WRSJR15U (0.15) B 41.7/20.1
R162 7510001661 S.TMR NTCG16 4LH 473JT B 47.1/20.7
R163 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 48.3/26.6
R165 7510001770 S.TMR NTCG10 4LH 473JT T 27.6/42
R166 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 48.4/21.7
R167 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 20.9/6.6
R168 7030003860 S.RES ERJ3GE JPW V B 34.1/36
R169 7030003860 S.RES ERJ3GE JPW V B 44.9/36.7
R170 7030007340 S.RES ERJ2GEJ 153 X (15 k
)
Except [EXP-2] only T 40.6/36.4
R200 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 9.2/32.8
R201 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 10.8/35.1
R202 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 10.8/36.7
R203 7030005010 S.RES ERJ2GEJ 681 X (680) B 14.5/37.1
R204 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
B 18.4/46.6
R205 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 29.6/40.9
R250 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 7.2/32.2
R251 7030005040 S.RES ERJ2GEJ 472 X (4.7 k
)
B 7.5/25.7
R252 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 5/32.9
R253 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 9/27.8
R254 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 9/26.2
R255 7030007280 S.RES ERJ2GEJ 331 X (330) B 11.5/29.1
R256 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 12.4/17.5
R257 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 13.1/22.4
R258 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
B 10/20.1
R300 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 17.9/40.7
R301 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 26/39
R302 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 23.4/36.7
R303 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 21.9/37.2
R304 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 8.5/38.9
R305 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 15.2/38.5
R306 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 9.2/35.5
R307 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
T 10.8/35.5
R308 7030009280 S.RES ERJ2GEJ 391 X (390) T 10.6/38.8
R309 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
T 6.4/38.5
R310 7030008410 S.RES ERJ2GEJ 392 X (3.9 k
)
T 2.7/39.6
R311 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 5.2/36.8
R312 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 3.6/34.9
R313 7030005030 S.RES ERJ2GEJ 152 X (1.5 k
)
T 1.5/34.2
R314 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
T 4.2/28
R315 7030005530 S.RES ERJ2GEJ 100 X (10) T 1.2/27.7
R316 7030007270 S.RES ERJ2GEJ 151 X (150) T 1.2/30.7
R317 7030007290 S.RES ERJ2GEJ 222 X (2.2 k
)
T 2.1/26.3
R318 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
T 27.6/36.2
R319 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
B 22.5/42.9
R320 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
T 28.6/38.4
R321 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
T 12.4/38.8
R322 7030005720 S.RES ERJ2GEJ 563 X (56 k
)
T 4.4/29.2
R323 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
B 8.2/40
R324 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 2/8.3
R325 7030005050 S.RES ERJ2GEJ 103 X (10 k
)
T 15.6/39.8
R400 7030007300 S.RES ERJ2GEJ 332 X (3.3 k
)
B 19.7/44
R401 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 19.7/42.2
R402 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 20.8/38.4
R403 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 19.7/43.1
R404 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 19.9/37.9
R405 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 17.7/37
R406 7030004990 S.RES ERJ2GEJ 221 X (220) B 18.5/41.9
R407 7030010040 S.RES ERJ2GEJ-JPW B 21/36.7
R408 7030005530 S.RES ERJ2GEJ 100 X (10) B 18.5/43.5
R409 7030004990 S.RES ERJ2GEJ 221 X (220) B 21/35.8
R410 7030004990 S.RES ERJ2GEJ 221 X (220) B 22.6/36.7
R411 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 15.7/36.1
R412 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 14.8/30.2
R413 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 15.2/33.2
R414 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 15.2/29
R415 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 15.7/30.2
R416 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 15.2/32.3
R417 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 16.9/29.2
R418 7030004990 S.RES ERJ2GEJ 221 X (220) B 13.5/30.9
R419 7030005090 S.RES ERJ2GEJ 104 X (100 k
)
B 15.8/25.7
R420 7030005530 S.RES ERJ2GEJ 100 X (10) B 13.8/26.4
R421 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 16.2/21.2
R422 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 15.3/21.2
R423 7030009270 S.RES ERJ2GEJ 821 X (820) B 17.5/22.4
R450 7030005240 S.RES ERJ2GEJ 473 X (47 k
)
B 21.5/33.3
R451 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 20.2/32.4
R452 7030008300 S.RES ERJ2GEJ 184 X (180 k
)
B 20.5/34.9
R453 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 19/32
R454 7030005220 S.RES ERJ2GEJ 223 X (22 k
)
B 20.2/31.5
R455 7030005110 S.RES ERJ2GEJ 224 X (220 k
)
B 24.2/32.8
R456 7030005120 S.RES ERJ2GEJ 102 X (1 k
)
B 21.4/27.5
R457 7030004990 S.RES ERJ2GEJ 221 X (220) B 24.2/30.1
To Next Page
